SS-60400-025
ActiveBEL MAGNETIC SOLUTIONS
IN-LINE ADAPTER, CAT5E, ADAPTER, IN-LINE, RJ45, RJ45, SEALJACK SERIES
Deep-Dive with AI
Search across all available documentation for this part.
SS-60400-025
ActiveBEL MAGNETIC SOLUTIONS
IN-LINE ADAPTER, CAT5E, ADAPTER, IN-LINE, RJ45, RJ45, SEALJACK SERIES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SS-60400-025 |
|---|---|
| Contact Finish | Gold |
| Contact Finish Thickness | 50 µin |
| Contact Finish Thickness | 1.27 µm |
| Contact Material | Copper Alloy |
| Convert From (Adapter End) | Jack, 8p8c (RJ45) SealJack |
| Convert To (Adapter End) | 8p8c (RJ45), Jack |
| Features | Cap (Cover), Industrial Environments, Circular Threaded Coupling |
| Housing Material | Thermoplastic |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Mounting Feature | Front Side Nut, Rear Side Nut |
| Mounting Type | Bulkhead, Panel Mount |
| Ratings | Cat5e |
| Shielding | Unshielded |
| Type | Coupler |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 11.98 | |
| 10 | $ 10.62 | |||
| 25 | $ 10.21 | |||
| 50 | $ 9.80 | |||
| 200 | $ 9.25 | |||
| 400 | $ 8.44 | |||
| 600 | $ 7.89 | |||
| 1000 | $ 7.24 | |||
Description
General part information
SS-60400 Series
Modular Coupler Connector Jack, 8p8c (RJ45) SealJack To Jack, 8p8c (RJ45) Cat5e Unshielded
