PX0412/12P

Active

BULGIN LIMITED

CIRCULAR CONNECTOR, BUCCANEER 400 SERIES, PLUG, 12, PIN, CABLE MOUNT ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

BULGIN LIMITED

CIRCULAR CONNECTOR, BUCCANEER 400 SERIES, PLUG, 12, PIN, CABLE MOUNT ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	PX0412/12P

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Type	Crimp and Solder Cup
Features	UV Resistant
Housing Color	Black
Ingress Protection	IP68 - Dust Tight, Waterproof
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Note	Contacts Not Included
Number of Positions	12
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shielding	Unshielded
Type	For Male Pins

Part	Mounting Feature	Ingress Protection	Note	Contact Shape	Shielding	Type	Operating Temperature [Min]	Operating Temperature [Max]	Orientation	Features	Connector Type	Contact Type	Material Flammability Rating	Housing Color	Number of Positions	Primary Material
BULGIN LIMITED PX0412/08P	Bulkhead - Rear Side Nut	IP68 - Dust Tight Waterproof	Contacts Not Included	Circular	Unshielded	For Male Pins	-40 °C	80 C	Keyed	UV Resistant	Receptacle Housing	Crimp and Solder Cup	UL94 V-0	Black	8
BULGIN LIMITED PX0412/06S	Bulkhead - Rear Side Nut	IP68 - Dust Tight Waterproof	Contacts Not Included	Circular	Unshielded	For Female Sockets	-40 °C	80 C	Keyed	UV Resistant	Receptacle Housing	Crimp and Solder Cup	UL94 V-0	Black	6
BULGIN LIMITED PX0412/08S	Bulkhead - Rear Side Nut	IP68 - Dust Tight Waterproof	Contacts Not Included	Circular	Unshielded	For Female Sockets	-40 °C	80 C	Keyed	UV Resistant	Receptacle Housing	Crimp and Solder Cup	UL94 V-0	Black	8
BULGIN LIMITED PX0412/12P	Bulkhead - Rear Side Nut	IP68 - Dust Tight Waterproof	Contacts Not Included	Circular	Unshielded	For Male Pins	-40 °C	80 C	Keyed	UV Resistant	Receptacle Housing	Crimp and Solder Cup	UL94 V-0	Black	12	Plastic
BULGIN LIMITED PX0412/03P	Bulkhead - Rear Side Nut	IP68 - Dust Tight Waterproof	Contacts Not Included	Circular	Unshielded	For Male Pins	-40 °C	80 C	Keyed	UV Resistant	Receptacle Housing	Crimp and Solder Cup	UL94 V-0	Black	3

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

12 (Power) Position Circular Connector Receptacle Housing Panel Mount UV Resistant
