180-M15-103L021
ActiveMH Connectors
D SUB CONNECTOR, HD15, PLUG, 180 M SERIES, 15 CONTACTS, DE, SOLDER
Deep-Dive with AI
Search across all available documentation for this part.
180-M15-103L021
ActiveMH Connectors
D SUB CONNECTOR, HD15, PLUG, 180 M SERIES, 15 CONTACTS, DE, SOLDER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 180-M15-103L021 |
|---|---|
| Color | Black |
| Connector Style | High Density, D-Sub |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Contact Material | Brass |
| Contact Type | Signal |
| Current Rating (Amps) | 5 A |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Features | Grounding Indents, Shielded |
| Flange Feature | Cable Side |
| Material Flammability Rating | UL94 V-0 |
| Number of Positions | 15 |
| Number of Rows | 3 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Shell Material, Finish | Nickel Plated, Steel |
| Shell Size, Connector Layout [custom] | DE, E |
| Shell Size, Connector Layout [custom] | 1 |
| Shell Size, Connector Layout [custom] | High Density |
| Wire Gauge [Max] | 28 AWG |
| Wire Gauge [Min] | 24 AWG |
180-M15 Series
| Part | Shell Material, Finish | Contact Finish | Flange Feature | Current Rating (Amps) | Color | Contact Finish Thickness | Features | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Connector Style | Dielectric Material | Number of Rows | Material Flammability Rating | Wire Gauge [Min] | Wire Gauge [Max] | Contact Material | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MH Connectors | Nickel Plated Steel | Gold | Cable Side | 5 A | Black | Flash | Grounding Indents Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Brass | Male Pins Plug | 105 ░C | -55 °C | ||
MH Connectors | Nickel Plated Steel | Gold | Housing/Shell (Unthreaded) | 5 A | Black | Flash | Grounding Indents Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Brass | Male Pins Plug | 105 ░C | -55 °C | ||
MH Connectors | Nickel Plated Steel | Gold | Board Side (4-40) Mating Side Female Screwlock (4-40) | 3 A 5 A | Black | Flash | Board Lock Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polyamide (PA9T) Nylon 9T | 3 | UL94 V-0 | Copper Alloy | Receptacle Female Sockets | 125 °C | -55 °C | Solder | Panel Mount Through Hole | ||
MH Connectors | Nickel Plated Steel | Gold | 4-40 Board Side | 5 A | Black | Flash | Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polyamide (PA9T) Nylon 9T | 3 | UL94 V-0 | Copper Alloy | Receptacle Female Sockets | 125 °C | -55 °C | Solder | Panel Mount Through Hole | ||
MH Connectors | Nickel Plated Steel | Gold | Female Screwlock (4-40) Mating Side | 5 A | Black | Flash | Grounding Indents Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Brass | Male Pins Plug | 105 ░C | -55 °C | ||
MH Connectors | Nickel Plated Steel | Gold | Female Screwlock (4-40) Mating Side | 3 A | Black | Flash | Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Copper Alloy | Receptacle Female Sockets | 125 °C | -55 °C | ||
MH Connectors | Nickel Plated Steel | Gold | Housing/Shell (Unthreaded) | 3 A | Black | Flash | Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Copper Alloy | Receptacle Female Sockets | 125 °C | -55 °C | ||
MH Connectors | Nickel Plated Steel | Gold | 4-40 Board Side | 5 A | Black | Flash | Grounding Indents Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polyamide (PA9T) Nylon 9T | 3 | UL94 V-0 | Copper Alloy | Male Pins Plug | 125 °C | -55 °C | Solder | Panel Mount Through Hole | ||
MH Connectors | Nickel Plated Steel | Gold | Housing/Shell (Unthreaded) | 5 A | Black | Flash | Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polyamide (PA9T) Nylon 9T | 3 | UL94 V-0 | Copper Alloy | Receptacle Female Sockets | 125 °C | -55 °C | Solder | Panel Mount Through Hole | ||
MH Connectors | Nickel Plated Steel | Gold | Cable Side | 5 A | Black | Flash | Grounding Indents Shielded | 15 | DE E | 1 | High Density | Signal | D-Sub High Density | Polybutylene Terephthalate (PBT) Glass Filled | 3 | UL94 V-0 | 24 AWG | 28 AWG | Brass | Male Pins Plug | 105 ░C | -55 °C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
180-M15 Series
15 Position D-Sub, High Density Plug, Male Pins Connector
