09140123101

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN DD SERIES, MODULE, 12 CONTACTS, RECEPTACLE, CRIMP SOCKET

Search across all available documentation for this part.

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN DD SERIES, MODULE, 12 CONTACTS, RECEPTACLE, CRIMP SOCKET

Technical Specifications

Parameters and characteristics for this part

Specification	09140123101

Color	Gray
Connector Type	Module without Contacts
Contact Type	Han® D
Current Rating (Amps)	10 A
Gender	Female
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	12
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Termination Style	Crimp
Voltage Rating	250 VDC

Part	Current Rating (Amps)	Voltage Rating	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Color	Contact Type	Number of Positions	Gender	Connector Type	Termination Style	Housing Material
HARTING Technology Group 09140123002	10 A	250 VDC	125 °C	-40 °C	UL94 V-0	Gray	Han® D	12	Male	Module without Contacts	Crimp	Polycarbonate (PC)
HARTING Technology Group 09140123101	10 A	250 VDC	125 °C	-40 °C	UL94 V-0	Gray	Han® D	12	Female	Module without Contacts	Crimp	Polycarbonate (PC)
HARTING Technology Group 09140123102	10 A	250 VDC	125 °C	-40 °C	UL94 V-0	Gray	Han® D	12	Female	Module without Contacts	Crimp	Polycarbonate (PC)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

The 09140123101 is a Han DD® 12-way female Contact Module with crimp terminal, copper alloy contacts and RAL 7032 (light gray) polycarbonate insert.
