Parameters and characteristics for this part
| Specification | 4301.5208 |
|---|---|
| Accomodates a Fuse | False |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Male Blades - Module |
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
General part information
AC Power Entry Modules KEA PWR ENTRY MODUL W. FILTER 6A
Technical documentation and resources
AC Power Entry Modules KEA PWR ENTRY MODUL W. FILTER 6A
| Part | Termination | Termination | Termination | Mounting Type | Fuse Holder, Drawer | Current Rating - Appliance Inlet | Voltage Rating - Appliance Inlet | Material Flammability Rating | Current Rating - Filter | Connector Style | Approval Agency | Accomodates a Fuse | Connector Type | Filter Type | Ingress Protection | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Panel Thickness [Min] | Panel Thickness [Max] | Panel Thickness [Max] | Panel Thickness [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 10 A | 250 VAC | UL94 V-0 | 10 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | IP40 | ||||||||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 10 A | 250 VAC | UL94 V-0 | 10 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | IP40 | 33 mm | 29 mm | ||||||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Panel Mount Snap-In | Drawer Sold Separate | 4 A | 250 VAC | UL94 V-0 | 4 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | IP40 | 33 mm | 29.35 mm | 0.79 mm | 0.118 in | 3 mm | 0.031 " | ||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 1 A | 250 VAC | UL94 V-0 | 1 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | IP40 | 33 mm | 29 mm | ||||||
SCHURTER Inc. | IEC 320-C14 | Receptacle Male Blades - Module | ||||||||||||||||||||
SCHURTER Inc. | 0.189 " 4.8 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 1 A | 250 VAC | UL94 V-0 | 1 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | IP40 | 33 mm | 29 mm | Voltage Selector | ||||||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 2 A | 250 VAC | UL94 V-0 | 2 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | IP40 | ||||||||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Panel Mount Snap-In | Drawer Sold Separate | 6 A | 250 VAC | UL94 V-0 | 6 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | IP40 | 33 mm | 29.35 mm | 0.79 mm | 0.118 in | 3 mm | 0.031 " | ||
SCHURTER Inc. | 0.25 in | 6.3 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 10 A | 250 VAC | UL94 V-0 | 10 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | IP40 | 33 mm | 29 mm | ||||||
SCHURTER Inc. | 0.189 " 4.8 mm | Quick Connect | Flange Panel Mount | Drawer Sold Separate | 4 A | 250 VAC | UL94 V-0 | 4 A | IEC 320-C14 | CCC cULus ENEC | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | IP40 | 33 mm | 29 mm | Voltage Selector |
