811-430

Active

WAGO Corporation

FUSED TERMINAL BLOCK, 6 POSITIONS, 16 AWG, 6 AWG, 16 MM², CLAMP, 30 A

Search across all available documentation for this part.

Active

WAGO Corporation

FUSED TERMINAL BLOCK, 6 POSITIONS, 16 AWG, 6 AWG, 16 MM², CLAMP, 30 A

Technical Specifications

Parameters and characteristics for this part

Part	Current - IEC	Disconnect Type	Number of Levels	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Material - Insulation	Terminal - Width	Number of Positions	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Color	Termination Style	Voltage - IEC	Features	Type	Stripping Length [Min]	Stripping Length [Max]	Terminal - Width [y]
WAGO Corporation 811-411	32 A	Fuse	1	14 AWG	6 AWG	Polyamide (PA66) Nylon 6/6	17.5 mm	2	16 mm²	2.5 mm²	Gray	Push In Spring	600 V	LED Indicator	Disconnect	12 mm	13 mm
WAGO Corporation 811-421	32 A	Fuse	1	14 AWG	6 AWG	Polyamide (PA66) Nylon 6/6		4	16 mm²	2.5 mm²	Gray	Push In Spring	600 V	LED Indicator	Disconnect	12 mm	13 mm	35 mm
WAGO Corporation 811-431	32 A	Fuse	1	14 AWG	6 AWG	Polyamide (PA66) Nylon 6/6		6	16 mm²	2.5 mm²	Gray	Push In Spring	600 V	LED Indicator	Disconnect	12 mm	13 mm	52.5 mm
WAGO Corporation 811-430	32 A	Fuse	1	14 AWG	6 AWG	Polyamide (PA66) Nylon 6/6		6	16 mm²	2.5 mm²	Gray	Push In Spring	600 V		Disconnect	12 mm	13 mm	52.5 mm
WAGO Corporation 811-410	32 A	Fuse	1	14 AWG	6 AWG	Polyamide (PA66) Nylon 6/6	17.5 mm	2	16 mm²	2.5 mm²	Gray	Push In Spring	600 V		Disconnect	12 mm	13 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Terminal Block Connector 6 Position Disconnect Gray 6-14 AWG
