4312NH3

Active

ebm-papst Inc.

DC AXIAL FAN, 12 V, SQUARE, 119 MM, 32 MM, BALL BEARING, 167 CFM

Deep-Dive with AI

Search across all available documentation for this part.

Documents4300N Series Datasheet +1

4312NH3

Active

ebm-papst Inc.

DC AXIAL FAN, 12 V, SQUARE, 119 MM, 32 MM, BALL BEARING, 167 CFM

Deep-Dive with AI

Documents4300N Series Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	4312NH3

Air Flow	167 CFM
Air Flow	4.68 m³/min
Bearing Type	Ball
Fan Type	Tubeaxial
Lifetime @ Temp.	45000 Hrs
Material - Blade	Polyamide (PA), Nylon, Fiberglass Reinforced
Material - Frame	Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Noise	55 dB
Operating Temperature [Max]	75 ░C
Operating Temperature [Max]	75 °C
Operating Temperature [Min]	-20 C
Operating Temperature [Min]	-20 °C
Power (Watts)	12 W
RPM	4050 RPM
Size / Dimension [x]	119 mm
Size / Dimension [y]	119 mm
Termination	2 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.2 VDC
Voltage Range [Min]	7 V
Weight	0.553 lb
Weight	250.84 g
Width [y]	32 mm

4312N Series

Part	Voltage - Rated	Lifetime @ Temp.	Fan Type	RPM	Voltage Range [Max]	Voltage Range [Min]	Width [y]	Air Flow	Air Flow	Approval Agency	Bearing Type	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Max]	Termination	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	Noise	Material - Frame	Weight	Weight	Material - Blade	Air Flow
ebm-papst Inc. 4312NN	12 VDC	72500 Hrs	Tubeaxial	2700 RPM	15 V	6 VDC	32 mm	112 CFM	3.14 m³/min	CE CSA UL VDE	Ball	-20 C	-20 °C	75 ░C	75 °C	2 Wire Leads	119 mm	119 mm	4.3 W	43 dB	Polybutylene Terephthalate (PBT) Fiberglass Reinforced	0.553 lb	250.84 g	Fiberglass Reinforced Nylon Polyamide (PA)
ebm-papst Inc. 4312NHH	12 VDC	52500 Hrs	Tubeaxial	3600 RPM	14.4 VDC	6 VDC	32 mm	4.12 m³/min		CE CSA UL VDE	Ball	-20 C	-20 °C	70 °C	70 °C	2 Wire Leads	119 mm	119 mm	10.7 W	51 dB(A)	Polybutylene Terephthalate (PBT) Fiberglass Reinforced	0.553 lb	250.84 g	Fiberglass Reinforced Nylon Polyamide (PA)	147 CFM
ebm-papst Inc. 4312NH3	12 VDC	45000 Hrs	Tubeaxial	4050 RPM	13.2 VDC	7 V	32 mm	4.68 m³/min			Ball	-20 C	-20 °C	75 ░C	75 °C	2 Wire Leads	119 mm	119 mm	12 W	55 dB	Polybutylene Terephthalate (PBT) Fiberglass Reinforced	0.553 lb	250.84 g	Fiberglass Reinforced Nylon Polyamide (PA)	167 CFM
ebm-papst Inc. 4312NH	12 VDC	62500 Hrs	Tubeaxial	3150 RPM	15 V	6 VDC	32 mm	3.62 m³/min		CE CSA UL VDE	Ball	-20 C	-20 °C	75 ░C	75 °C	2 Wire Leads	119 mm	119 mm	6.5 W	47 dB	Polybutylene Terephthalate (PBT) Fiberglass Reinforced	0.553 lb	250.84 g	Fiberglass Reinforced Nylon Polyamide (PA)	129.3 CFM

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 50.76
		10	$ 46.36
		25	$ 44.60
		50	$ 41.66
		100	$ 38.44
		250	$ 37.85
Newark	Each	25	$ 48.49
		50	$ 45.79
		100	$ 43.10

Description

General part information

4312N Series

ebm-papst offers a wide range of DC axial fans from 25 mm to 280 mm in size. Many DC fans can be operated on voltages that are up to 50% lower and 25% higher than their nominal voltage (see voltage range in the data sheet). This allows the air performance to be adapted to the cooling requirements and the noise to be reduced, even if the fan does not have a control input.

Documents

Technical documentation and resources

4300N Series

Datasheet

Technical Data Sheet EN

Datasheet
