WR9HA2000USBCFMEDR6W

Active

GlobTek, Inc.

AC/DC WALL MOUNT ADAPTER 5V 10W

Search across all available documentation for this part.

Active

GlobTek, Inc.

AC/DC WALL MOUNT ADAPTER 5V 10W

Technical Specifications

Parameters and characteristics for this part

Specification	WR9HA2000USBCFMEDR6W

Applications	Household Appliances, ITE (Commercial), Medical
Approval Agency	RCM, LPS, VCCI, UKRSepro, ETL, cETLus, EAC, CB, PSE
Cord Length	60.2 in
Cord Length	1.53 m
Current - Output (Max) [Max]	2 A
Efficiency	CoC Tier 2, Level VI
Form	Wall Mount (Class II)
Input Connector	NEMA 1-15P
Input Type	Fixed Blade
Output Connector	USB C
Power (Watts)	10 W
Region Utilized	North America
Size / Dimension [x]	2.72 "
Size / Dimension [x]	69 mm
Size / Dimension [y]	28.8 mm
Size / Dimension [y]	1.13 in
Size / Dimension [z]	57.3 mm
Size / Dimension [z]	2.26 "
Standard Number	60335-1, 60601-1-11, 60601-1-2, 62368-1
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Output	5 V

Part	Input Type	Voltage - Output	Applications	Power (Watts)	Output Connector	Efficiency	Cord Length	Cord Length	Region Utilized	Approval Agency	Standard Number	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output (Max) [Max]	Input Connector	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Form	No Load Power Consumption [Max]
GlobTek, Inc. WR9HA2000USBCFMEDR6W	Fixed Blade	5 V	Household Appliances ITE (Commercial) Medical	10 W	USB C	CoC Tier 2 Level VI	60.2 in	1.53 m	North America	CB cETLus EAC ETL LPS PSE RCM UKRSepro VCCI	60335-1 60601-1-11 60601-1-2 62368-1	90 VAC	264 VAC	2 A	NEMA 1-15P	2.72 "	69 mm	57.3 mm	28.8 mm	1.13 in	2.26 "	Wall Mount (Class II)
GlobTek, Inc. WR9HA2000USBC-F(R6B)	Fixed Blade	5 V	ITE (Commercial)	10 W	USB C	CoC Tier 2 Level VI	59 in	1.5 m	North America	CB cULus EAC FCC LPS PSE UKRSepro VCCI	60950-1	90 VAC	264 VAC	2 A	NEMA 1-15P	2.72 "	69 mm	57.3 mm	28.8 mm	1.13 in	2.26 "	Wall Mount (Class II)	75 mW
GlobTek, Inc. WR9HA2000MICB-MFR6B	Fixed Blade	5 V	Household Appliances ITE (Commercial) Medical	10 W	USB Micro	Level VI	60.2 in	1.53 m	North America	CB cETLus EAC ETL LPS PSE RCM UKRSepro VCCI	60335-1 60601-1-11 60601-1-2 62368-1	90 VAC	264 VAC	2 A	NEMA 1-15P	2.72 "	69 mm	40.3 mm	28.8 mm	1.13 in	1.59 "	Wall Mount (Class II)
GlobTek, Inc. WR9HA2000UUSB-F(R6B)	Fixed Blade	5 V	ITE (Commercial)	10 W	USB Micro	Level VI	60.2 in	1.53 m	North America	CB cULus EAC FCC LPS PSE UKRSepro VCCI	60950-1	90 VAC	264 VAC	2 A	NEMA 1-15P	2.72 "	69 mm	40.3 mm	28.8 mm	1.13 in	1.59 "	Wall Mount (Class II)	75 mW

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5V 10 W AC/DC External Wall Mount (Class II) Adapter Fixed Blade Input
