B10B-PH-TW-S

Active

JST Sales America Inc.

CONN ADAPT PLUG/PLUG 10POS 2MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsJST Prefix Suffix Chart Datasheet

B10B-PH-TW-S

Active

JST Sales America Inc.

CONN ADAPT PLUG/PLUG 10POS 2MM

Deep-Dive with AI

DocumentsJST Prefix Suffix Chart Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	B10B-PH-TW-S

Convert From (Adapter End)	Plug, Male Pins
Mounting Type	Free Hanging (In-Line)
Number of Positions	10
Number of Rows	1
Pitch [x]	0.079 in
Pitch [x]	2 mm

B10B-PH Series

Part	Material Flammability Rating	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Mated Stacking Heights	Contact Type	Current Rating (Amps)	Pitch - Mating [x]	Pitch - Mating [x]	Mounting Type	Row Spacing - Mating	Row Spacing - Mating	Insulation Color	Style	Fastening Type	Voltage Rating	Termination	Overall Contact Length	Overall Contact Length	Number of Rows	Contact Material	Contact Length - Post	Contact Length - Post	Insulation Height	Insulation Height	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Shrouding	Insulation Material	Number of Positions	Contact Shape	Number of Positions Loaded	Pitch [x]	Pitch [x]	Convert From (Adapter End)	Features	Overall Contact Length [x]	Contact Length - Post [x]	Contact Length - Post [x]
JST Sales America Inc. B10B-PHDSS	UL94 V-0	Tin	0.114 in	2.9 mm	8.8 mm	Male Pin	3 A	0.079 in	2 mm	Through Hole	0.079 in	2 mm	Natural	Board to Cable/Wire	Detent Lock	250 VDC	Solder	0.291 in	7.4 mm	2	Copper Alloy	0.118 in	3 mm	6.5 mm	0.256 in	Header	-25 °C	85 °C	Shrouded - 4 Wall	Glass Filled Nylon Polyamide (PA)	10	Square	All
JST Sales America Inc. B10B-PH-TW-S										Free Hanging (In-Line)										1											10			0.079 in	2 mm	Plug Male Pins
JST Sales America Inc. B10B-PH-SM4-TB	UL94 V-0	Tin	0.13 in	3.3 mm	8.6 mm	Male Pin	2 A	0.079 in	2 mm	Surface Mount			Natural	Board to Cable/Wire	Detent Lock	100 V	Solder			1	Copper Alloy			6.6 mm	0.26 in	Header	-25 °C	85 °C	Shrouded - 4 Wall	Nylon 6T Polyamide (PA6T)	10	Square	All				Solder Retention
JST Sales America Inc. B10B-PH-K-S	UL94 V-0	Tin	0.13 in	3.3 mm	8 mm	Male Pin	2 A	0.079 in	2 mm	Through Hole			Natural	Board to Cable/Wire	Detent Lock	100 V	Press-Fit Solder		8.45 mm	1	Brass			6 mm	0.236 in	Header	-25 °C	85 °C	Shrouded - 4 Wall	Polyamide (PA66) Nylon 6/6	10	Square	All					0.333 in	0.134 in	3.4 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.71
		10	$ 0.62
		250	$ 0.47
		500	$ 0.44
		1000	$ 0.37
		5000	$ 0.32
		10000	$ 0.30

Description

General part information

B10B-PH Series

10 Position Adapter Connector Plug, Male Pins To Plug, Male Pins 0.079" (2.00mm)

Documents

Technical documentation and resources

JST Prefix Suffix Chart

Datasheet
