Technical Specifications

Parameters and characteristics for this part

Specification	FX23L-20P-0.5SV12(20)

Connector Type	Header, Outer Shroud Contacts
Contact Finish	Gold
Contact Finish Thickness	4 Áin
Contact Finish Thickness	0.1 Ám
Features	Board Guide
Height Above Board	0.427 in
Height Above Board	10.85 mm
Mounting Type	Surface Mount
Number of Positions	24
Number of Positions [custom]	4
Number of Rows	2
Pitch [x]	0.5 mm
Pitch [x]	0.02 in

FX23L Series

Part	Number of Positions	Number of Positions [custom]	Number of Rows	Mounting Type	Connector Type	Height Above Board	Height Above Board	Features	Contact Finish Thickness	Contact Finish Thickness	Pitch [x]	Pitch [x]	Contact Finish
Hirose Electric USA, Inc. FX23L-20P-0.5SV12(20)	24	4	2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-20S-0.5SV	24	4	2	Surface Mount	Center Strip Contacts Receptacle	0.228 in	5.8 mm	Board Guide Pick and Place	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-20P-0.5SV12	24	4	2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-40P-0.5SV12	44		2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-20P-0.5SV12(01)	24	4	2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-40S-0.5SV	44		2	Surface Mount	Center Strip Contacts Receptacle	0.228 in	5.8 mm	Board Guide Pick and Place	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-20P-0.5SV8	24	4	2	Surface Mount	Header Outer Shroud Contacts	0.27 in	6.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-60P-0.5SV12	4 60		2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-100P-0.5SV10(20)	104		2	Surface Mount	Header Outer Shroud Contacts			Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
Hirose Electric USA, Inc. FX23L-100P-0.5SV12	104		2	Surface Mount	Header Outer Shroud Contacts	0.427 in	10.85 mm	Board Guide	4 Áin	0.1 Ám	0.5 mm	0.02 in	Gold
