GT13-1P-DS(71)

Obsolete

Hirose Electric USA, Inc.

CONN COAX RCPT R/A 50 OHM PCB

Search across all available documentation for this part.

Obsolete

Hirose Electric USA, Inc.

CONN COAX RCPT R/A 50 OHM PCB

Technical Specifications

Parameters and characteristics for this part

Specification	GT13-1P-DS(71)

Center Contact Plating	Tin
Connector Style	Coaxial
Connector Type	Male Pin, Receptacle
Contact Termination	Solder
Dielectric Material	Polybutylene Terephthalate (PBT)
Fastening Type	Push-Pull
Frequency - Max [Max]	1 GHz
Impedance	50 Ohms
Mating Cycles	30
Mounting Type	Through Hole, Right Angle
Number of Ports	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-30 ░C
Voltage Rating	250 VDC

Bench Top Tools CRIMP TERM 20-22 AWG GT13

Part	Fastening Type	Dielectric Material	Body Material	Center Contact Plating	Features	Housing Color	Center Contact Material	Number of Ports	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Termination	Frequency - Max [Max]	Connector Style	Mating Cycles	Impedance	Mounting Type	Voltage Rating	For Use With/Related Products	Accessory Type	Color
Hirose Electric USA, Inc. GT13S-1/1/1/1PP-DS	Push-Pull	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)	Tin	Board Lock Mounting Flange	Gray	Copper Alloy	4	-30 ░C	105 ░C	Male Pin Receptacle	Solder	1 GHz	Coaxial	30	50 Ohms	Through Hole Right Angle	250 VDC
Hirose Electric USA, Inc. GT13-1P-DS(71)	Push-Pull	Polybutylene Terephthalate (PBT)		Tin				1	-30 ░C	105 ░C	Male Pin Receptacle	Solder	1 GHz	Coaxial	30	50 Ohms	Through Hole Right Angle	250 VDC
Hirose Electric USA, Inc. GT13-1S-HU														F					F Terminals	Housing
Hirose Electric USA, Inc. GT13/5-2/1S-HU			Polybutylene Terephthalate (PBT)		3 Positions									F					F Terminals	Housing	Gray
Hirose Electric USA, Inc. GT13-1P-DS(70)	Push-Pull	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)	Tin		Gray	Brass	1	-30 ░C	105 ░C	Male Pin Receptacle	Solder	1 GHz	Coaxial	30	50 Ohms	Through Hole Right Angle	250 VDC
Hirose Electric USA, Inc. GT13/5-2/1P-R			Polybutylene Terephthalate (PBT)																GT13 Housings 3 Positions	Retainer	Gray
Hirose Electric USA, Inc. GT13/5-2/1S-R			Polybutylene Terephthalate (PBT)																GT13 Housings 3 Positions	Retainer	Gray
