SSM1A430M7

Obsolete

SQUARE D BY SCHNEIDER ELECTRIC

SSR RELAY SPST-NO 30A 48-600V

Search across all available documentation for this part.

Obsolete

SQUARE D BY SCHNEIDER ELECTRIC

SSR RELAY SPST-NO 30A 48-600V

Technical Specifications

Parameters and characteristics for this part

Specification	SSM1A430M7

Approval Agency	CSA, UL
Load Current	30 A
Mounting Type	DIN Rail
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-30 ░C
Output Type	AC
Package / Case	SSR with Integrated Heat Sink
Termination Style	Screw Terminal
Voltage - Input [Max]	280 VAC/DC
Voltage - Input [Min]	90 VAC
Voltage - Load [Max]	600 V
Voltage - Load [Min]	48 V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency	Output Type	Voltage - Load [Min]	Voltage - Load [Max]	Mounting Type	Load Current	Termination Style	Package / Case
SQUARE D BY SCHNEIDER ELECTRIC SSM1A312B7	18 VAC/DC	36 VAC	-30 ░C	80 C	CSA UL	AC	48 V	600 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A312P7R	200 VAC	265 VAC	-30 ░C	80 C	CSA UL	AC	48 V	600 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A112F7R	90 VAC	140 VAC	-30 ░C	80 C	CSA UL	AC	24 V	280 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A112BD	4 V	32 V	-30 ░C	80 C	CSA UL	AC Zero Cross	24 V	280 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A16B7	18 VAC/DC	36 VAC	-30 ░C	80 C	CSA UL	AC Zero Cross	24 V	280 V	DIN Rail	6 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A430M7	90 VAC	280 VAC/DC	-30 ░C	80 C	CSA UL	AC	48 V	600 V	DIN Rail	30 A	Screw Terminal	SSR with Integrated Heat Sink
SQUARE D BY SCHNEIDER ELECTRIC SSM1A312F7	90 VAC	140 VAC	-30 ░C	80 C	CSA UL	AC	48 V	600 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A112B7R	18 VAC/DC	36 VAC	-30 ░C	80 C	CSA UL	AC	24 V	280 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A112BDR	4 V	32 V	-30 ░C	80 C	CSA UL	AC	24 V	280 V	DIN Rail	12 A	Screw Terminal	Module
SQUARE D BY SCHNEIDER ELECTRIC SSM1A16P7	200 VAC	265 VAC	-30 ░C	80 C	CSA UL	AC Zero Cross	24 V	280 V	DIN Rail	6 A	Screw Terminal	Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Solid State SPST-NO (1 Form A) SSR with Integrated Heat Sink
