0351800404
ActiveMolex
CONN HSG RCPT 4POS 8.70MM BLUE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
0351800404
ActiveMolex
CONN HSG RCPT 4POS 8.70MM BLUE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 0351800404 |
|---|---|
| Color | Blue |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Blade Socket, Male Blade |
| Fastening Type | Locking Ramp |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Note | Contacts Not Included |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 0.343 in |
| Pitch [x] | 8.7 mm |
| Row Spacing | 8 mm |
| Row Spacing | 0.315 in |
| Stacking Direction | Top to Bottom and Side to Side |
| Voltage Rating | 300 VDC |
035180 Series
| Part | Row Spacing | Row Spacing | Stacking Direction | Number of Positions | Material - Insulation | Contact Type | Voltage Rating | Number of Rows | Note | Fastening Type | Connector Type | Contact Termination | Color | Pitch [x] | Pitch [x] | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | |||||||||||||||||
Molex | |||||||||||||||||
Molex | 8 mm | 0.315 in | Top to Bottom and Side to Side | 4 | Polybutylene Terephthalate (PBT) | Female Blade Socket Male Blade | 300 VDC | 2 | Contacts Not Included | Locking Ramp | Receptacle | Crimp | Blue | 0.343 in | 8.7 mm | -40 °C | 120 °C |
Molex | 8 mm | 0.315 in | Top to Bottom and Side to Side | 6 | Polycarbonate (PC) Polyethylene Terephthalate (PET) | Female Blade Socket Male Blade | 2 | Contacts Not Included | Locking Ramp | Plug | Crimp | Yellow | 0.335 in | 8.5 mm | -40 °C | 120 °C | |
Molex | 8 mm | 0.315 in | Top to Bottom and Side to Side | 4 | Polycarbonate (PC) Polyethylene Terephthalate (PET) | Female Blade Socket Male Blade | 2 | Contacts Not Included | Locking Ramp | Plug | Crimp | Yellow | 0.343 in | 8.7 mm | -40 °C | 120 °C | |
Molex | 8 mm | 0.315 in | Top to Bottom and Side to Side | 4 | Polycarbonate (PC) Polyethylene Terephthalate (PET) | Female Blade Socket Male Blade | 2 | Contacts Not Included | Locking Ramp | Plug | Crimp | Yellow | 0.343 in | 8.7 mm | -40 °C | 120 °C | |
Molex | 8 mm | 0.315 in | Top to Bottom and Side to Side | 6 | Polybutylene Terephthalate (PBT) | Female Blade Socket Male Blade | 2 | Contacts Not Included | Locking Ramp | Plug | Crimp | Natural | 0.335 in | 8.5 mm | -40 °C | 120 °C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 7200 | $ 0.26 | |
Description
General part information
035180 Series
4 Position Blade Type Power Housing Connector Receptacle Blue 0.343" (8.70mm)
