0351510114
ActiveMolex
CONN HSG PLUG 1POS BLUE
Deep-Dive with AI
Search across all available documentation for this part.
0351510114
ActiveMolex
CONN HSG PLUG 1POS BLUE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0351510114 |
|---|---|
| Color | Blue |
| Connector Type | Plug |
| Contact Termination | Crimp |
| Contact Type | Female Blade Socket |
| Fastening Type | Latch Lock |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 1 |
| Number of Rows | 1 |
| Operating Temperature [Max] | 120 °C |
| Operating Temperature [Min] | -40 °C |
035151 Series
| Part | Contact Type | Fastening Type | Number of Rows | Contact Termination | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Color | Connector Type | Material - Insulation | Number of Positions | Note | Pitch [x] | Pitch [x] | Row Spacing | Row Spacing | Stacking Direction | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | ||||||||||||||||||
Molex | Female Blade Socket | Latch Lock | 1 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Blue | Plug | Polybutylene Terephthalate (PBT) | 1 | Contacts Not Included | ||||||
Molex | Female Blade Socket | Latch Lock | 1 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Natural | Plug | Polybutylene Terephthalate (PBT) | 1 | Contacts Not Included | ||||||
Molex | Female Blade Socket Male Blade | Latch Lock | 2 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Natural | Plug | Polycarbonate (PC) Polyethylene Terephthalate (PET) | 6 | Contacts Not Included | 0.287 in | 7.3 mm | 7.8 mm | 0.307 in | Top to Bottom and Side to Side | |
Molex | ||||||||||||||||||
Molex | Female Blade Socket Male Blade | Latch Lock | 2 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Natural | Receptacle | Polybutylene Terephthalate (PBT) | 4 | Contacts Not Included | 0.244 in | 6.2 mm | 8.9 mm | 0.35 in | Top to Bottom and Side to Side | |
Molex | Female Blade Socket | Latch Lock | 1 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Natural | Receptacle | Polycarbonate (PC) Polyethylene Terephthalate (PET) | 2 | Contacts Not Included | 0.244 in | 6.2 mm | Side to Side | |||
Molex | Female Blade Socket Male Blade | Latch Lock | 1 | Crimp | Free Hanging (In-Line) | -40 °C | 110 °C | Natural | Plug | 1 | Contacts Not Included | Side to Side | 300 VDC | |||||
Molex | Female Blade Socket Male Blade | Latch Lock | 2 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Blue | Receptacle | Polybutylene Terephthalate (PBT) | 4 | Contacts Not Included | 0.244 in | 6.2 mm | 8.9 mm | 0.35 in | Top to Bottom and Side to Side | |
Molex | Female Blade Socket Male Blade | Latch Lock | 1 | Crimp | Free Hanging (In-Line) | -40 °C | 120 °C | Blue | Plug | Polybutylene Terephthalate (PBT) | Contacts Not Included | 0.287 in | 7.3 mm | Side to Side |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 33000 | $ 0.11 | |
Description
General part information
035151 Series
1 Position Blade Type Power Housing Connector Plug Blue
Documents
Technical documentation and resources
No documents available
