M3UGK-3418J
Unknown3M (TC)
IDC CABLE - MKS34K/MC34G/MCS34K
Deep-Dive with AI
Search across all available documentation for this part.
M3UGK-3418J
Unknown3M (TC)
IDC CABLE - MKS34K/MC34G/MCS34K
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M3UGK-3418J |
|---|---|
| Cable Termination | IDC |
| Connector Type | Socket to Card Edge |
| Contact Finish | Gold |
| Contact Finish Thickness | 0.76 Ám |
| Contact Finish Thickness | 30 Áin |
| Features | Polarizing Key, Flange (Card Edge), Strain Relief (Socket) |
| Length [x] | 457.2 mm |
| Length [x] | 1.5 ft |
| Number of Positions | 34 |
| Number of Rows | 2 |
| Pitch - Cable | 0.05 " |
| Pitch - Cable | 1.27 mm |
| Pitch - Connector | 0.1 in |
| Pitch - Connector | 2.54 mm |
| Shielding | Unshielded |
M3UGK Series
| Part | Color | Contact Finish | Pitch - Cable | Pitch - Cable | Shielding | Pitch - Connector | Pitch - Connector | Length | Length | Length | Features | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Cable Termination | Connector Type | Number of Rows | Number of Positions | Length | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3M (TC) | Multiple Ribbon | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 152.4 mm | 6 " | 0.5 ' | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 50 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | ||||
3M (TC) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 152.4 mm | 6 " | 0.5 ' | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 10 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | |||||
3M (TC) | Multiple Ribbon | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 152.4 mm | 6 " | 0.5 ' | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 34 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | ||||
3M (TC) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 152.4 mm | 6 " | 0.5 ' | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 40 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | |||||
3M (TC) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 152.4 mm | 6 " | 0.5 ' | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 16 | |||||
3M (TC) | Multiple Twisted Pair (Flat) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | 1.52 m | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 16 | 5 ' | |||||
3M (TC) | Multiple Twisted Pair (Flat) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 40 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 1.02 m | 3.34 ft | |||||
3M (TC) | Multiple Ribbon | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 16 | 457.2 mm | 1.5 ft | |||||
3M (TC) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 40 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 914.4 mm | 3 ft | ||||||
3M (TC) | Gold | 0.05 " | 1.27 mm | Unshielded | 0.1 in | 2.54 mm | Flange (Card Edge) Polarizing Key Strain Relief (Socket) | 34 | 0.76 Ám | 30 Áin | IDC | Socket to Card Edge | 2 | 457.2 mm | 1.5 ft |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 38.14 | |
| 10 | $ 33.40 | |||
| 25 | $ 31.96 | |||
| 50 | $ 30.93 | |||
| 100 | $ 29.90 | |||
| 250 | $ 28.25 | |||
Description
General part information
M3UGK Series
34 Position Cable Assembly Rectangular Socket to Card Edge 1.50' (457.20mm)
