M3UGK-4036J

Active

3M (TC)

IDC CABLE - MKS40K/MC40G/MCS40K

Deep-Dive with AI

Search across all available documentation for this part.

Documents3365 Series Datasheet Ribbon Cable Assembly Length Guide +1

M3UGK-4036J

Active

3M (TC)

IDC CABLE - MKS40K/MC40G/MCS40K

Deep-Dive with AI

Documents3365 Series Datasheet Ribbon Cable Assembly Length Guide +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M3UGK-4036J

Cable Termination	IDC
Connector Type	Socket to Card Edge
Contact Finish	Gold
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Features	Polarizing Key, Flange (Card Edge), Strain Relief (Socket)
Length [x]	3 ft
Length [x]	914.4 mm
Number of Positions	40
Number of Rows	2
Pitch - Cable	0.05 "
Pitch - Cable	1.27 mm
Pitch - Connector	0.1 in
Pitch - Connector	2.54 mm
Shielding	Unshielded

M3UGK Series

Part	Color	Contact Finish	Pitch - Cable	Pitch - Cable	Shielding	Pitch - Connector	Pitch - Connector	Length	Length	Length	Features	Number of Positions	Contact Finish Thickness	Contact Finish Thickness	Cable Termination	Connector Type	Number of Rows	Number of Positions	Length	Length [x]	Length [x]
3M (TC) M3UGK-5006R	Multiple Ribbon	Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '	Flange (Card Edge) Polarizing Key Strain Relief (Socket)	50	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2
3M (TC) M3UGK-1006J		Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '	Flange (Card Edge) Polarizing Key Strain Relief (Socket)	10	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2
3M (TC) M3UGK-3406R	Multiple Ribbon	Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '	Flange (Card Edge) Polarizing Key Strain Relief (Socket)	34	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2
3M (TC) M3UGK-4006J		Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '	Flange (Card Edge) Polarizing Key Strain Relief (Socket)	40	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2
3M (TC) M3UGK-1606J		Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '	Flange (Card Edge) Polarizing Key Strain Relief (Socket)		0.76 Ám	30 Áin	IDC	Socket to Card Edge	2	16
3M (TC) M3UGK-1660K	Multiple Twisted Pair (Flat)	Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm	1.52 m			Flange (Card Edge) Polarizing Key Strain Relief (Socket)		0.76 Ám	30 Áin	IDC	Socket to Card Edge	2	16	5 '
3M (TC) M3UGK-4040K	Multiple Twisted Pair (Flat)	Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm				Flange (Card Edge) Polarizing Key Strain Relief (Socket)	40	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2			1.02 m	3.34 ft
3M (TC) M3UGK-1618R	Multiple Ribbon	Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm				Flange (Card Edge) Polarizing Key Strain Relief (Socket)		0.76 Ám	30 Áin	IDC	Socket to Card Edge	2	16		457.2 mm	1.5 ft
3M (TC) M3UGK-4036J		Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm				Flange (Card Edge) Polarizing Key Strain Relief (Socket)	40	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2			914.4 mm	3 ft
3M (TC) M3UGK-3418J		Gold	0.05 "	1.27 mm	Unshielded	0.1 in	2.54 mm				Flange (Card Edge) Polarizing Key Strain Relief (Socket)	34	0.76 Ám	30 Áin	IDC	Socket to Card Edge	2			457.2 mm	1.5 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 65.88
		10	$ 60.46
		25	$ 58.13
		50	$ 56.20
		100	$ 53.09

Description

General part information

M3UGK Series

40 Position Cable Assembly Rectangular Socket to Card Edge 3.00' (914.40mm)

Documents

Technical documentation and resources

3365 Series Datasheet

Datasheet

Ribbon Cable Assembly Length Guide

Datasheet
