FL-B101Q-HZ

Active

Texmate

LINE FREQUENCY 0-99.9 HZ BARGRAP

Search across all available documentation for this part.

Active

Texmate

LINE FREQUENCY 0-99.9 HZ BARGRAP

Technical Specifications

Parameters and characteristics for this part

Part	Type	Output Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Display Type	Termination Style	Measuring Type	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Measuring Range [Max]	Measuring Range [Min]
Texmate FL-B101Q-HZ	Frequency Meter	Analog Relay (2)	85 VAC 95 VDC	265 VAC 300 VDC	LED - Red Bar Graph	Screw Terminal	Frequency	36.07 mm	144.53 mm
Texmate FL-B101Q-DCV	Process Meter		85 VAC 95 VDC	265 VAC 300 VDC	LED - Red Bar Graph	Screw Terminal	Process	36.07 mm	144.53 mm	200 V	2 VDC
Texmate FL-B101Q-ACV	Voltmeter	Analog Relay (2)	85 VAC 95 VDC	265 VAC 300 VDC	LED - Red Bar Graph	Screw Terminal	Voltage	36.07 mm	144.53 mm	600 VAC	200 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 684.00

General part information

Frequency Meter LED - Red Bar Graph Display Panel Mount
