ANT-DK-WF0EM01-I0200

Active

Adam Tech

RF ANT 2.45GHZ PCB TRACE SMD

Search across all available documentation for this part.

Active

Adam Tech

RF ANT 2.45GHZ PCB TRACE SMD

Technical Specifications

Parameters and characteristics for this part

Part	RF Family/Standard	Applications	Gain	Frequency Range [Max]	Frequency Range [Min]	Mounting Type	Number of Bands	VSWR	Termination	Power - Max [Max]	Antenna Type	Height (Max) [Max]	Height (Max) [Max]	Return Loss	Frequency Group	Frequency Group [Min]	Frequency Group [Max]	Frequency (Center/Band)	Features	Features	Height (Max)
Adam Tech ANT-DK-DB1DI-2AB(C)-	WiFi	WLAN	2 dBic	2.5 GHz 5.8 GHz	2.4 GHz 4.9 GHz	Connector Mount	2	1.92	RP-SMA	1 W	Tilt Whip	4.252 in	108 mm	-10 dB	4 GHz	2 GHz	3 GHz	2.45 GHz 5.35 GHz
Adam Tech ANT-DK-LTE1DIP-2AP(P)	Cellular	LTE	2 dBic	2.69 GHz 960 MHz	1.71 GHz 704 MHz	Connector Mount	2	1.92	SMA	1 W	Tilt Whip	6.339 in	161 mm	-10 dB		2 GHz 300 MHz	1 GHz 3 GHz	2.2 GHz 832 MHz
Adam Tech ANT-DK-WF0EM01-I0200	WiFi	Wi-Fi	2 dBic	2.5 GHz	2.4 GHz	Surface Mount	1	2	IPEX MHF1 U.FL (UMCC)		PCB Trace		0.058 in						Cable	200 mm	1.47 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2.45GHz Wi-Fi PCB Trace RF Antenna 2.4GHz ~ 2.5GHz 2dBi U.FL (UMCC), IPEX MHF1 Surface Mount
