X66AK2G01ZBB60

Obsolete

Texas Instruments

DSP FIXED-POINT/FLOATING-POINT 32BIT 600MHZ 625-PIN NFBGA

Search across all available documentation for this part.

Obsolete

Texas Instruments

DSP FIXED-POINT/FLOATING-POINT 32BIT 600MHZ 625-PIN NFBGA

Technical Specifications

Parameters and characteristics for this part

Specification	X66AK2G01ZBB60

Clock Rate	600 MHz
Interface	SPI, QSPI, McASP, MMC/SD, USB, CAN, Ethernet, UART, I2C, McBSP, DMA, EBI/EMI
Mounting Type	Surface Mount
Non-Volatile Memory	External
On-Chip RAM	1 MB
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	0 °C
Package / Case	625-LFBGA
Supplier Device Package	625-NFBGA (21x21)
Type	DSP+ARM®
Voltage - Core [custom]	0.9 V
Voltage - I/O	3.3 V, 1.8 V

Part	Type	On-Chip RAM	Interface	Clock Rate	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Core	Package / Case	Voltage - I/O	Supplier Device Package	Non-Volatile Memory	Non-Volatile Memory	Voltage - Core [custom]
Texas Instruments X66AK2H12AAAWA2	DSP+ARM®	12.75 MB	DMA EBI/EMI Ethernet I2C Serial RapidIO SPI UART/USART USB 3.0	1.2 GHz	-40 °C	100 °C	Surface Mount	Variable	1517-BBGA FCBGA	0.85 V 1 V 1.35 V 1.5 V 1.8 V 3.3 V	1517-FCBGA (40x40)	384 kB
Texas Instruments X66AK2G02ZBB60	DSP+ARM®	1 MB	CAN DMA EBI/EMI Ethernet I2C McASP McBSP MMC/SD QSPI SPI UART USB	600 MHz	0 °C	90 °C	Surface Mount		625-LFBGA	1.8 V 3.3 V	625-NFBGA (21x21)		External	0.9 V
Texas Instruments X66AK2E05XABD25	DSP+ARM®	2 MB	DMA EBI/EMI Ethernet I2C PCIe SPI TSIP UART USB 3.0 USIM	1.25 GHz	0 °C	85 °C	Surface Mount	Variable	1089-BFBGA FCBGA	1.35 V 1.5 V 1.8 V 3.3 V	1089-FCBGA (27x27)	256 kB
Texas Instruments X66AK2H12AAW2	DSP+ARM®	12.75 MB	DMA EBI/EMI Ethernet I2C Serial RapidIO SPI UART/USART USB 3.0	1.2 GHz	0 °C	85 °C	Surface Mount	Variable	1517-BBGA FCBGA	0.85 V 1 V 1.35 V 1.5 V 1.8 V 3.3 V	1517-FCBGA (40x40)	384 kB
Texas Instruments X66AK2G01ZBB60	DSP+ARM®	1 MB	CAN DMA EBI/EMI Ethernet I2C McASP McBSP MMC/SD QSPI SPI UART USB	600 MHz	0 °C	90 °C	Surface Mount		625-LFBGA	1.8 V 3.3 V	625-NFBGA (21x21)		External	0.9 V
Texas Instruments X66AK2H06AAAW2	DSP+ARM®	8.375 MB	DMA EBI/EMI Ethernet I2C Serial RapidIO SPI UART/USART USB 3.0	1.2 GHz	0 °C	85 °C	Surface Mount	Variable	1517-BBGA FCBGA	0.85 V 1 V 1.35 V 1.5 V 1.8 V 3.3 V	1517-FCBGA (40x40)	384 kB

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

DSP FIXED-POINT/FLOATING-POINT 32BIT 600MHZ 625-PIN NFBGA
