Technical Specifications
Parameters and characteristics for this part
| Specification | CS4207-CNZ |
|---|---|
| Data Interface | S/PDIF, HDA |
| Dynamic Range, ADCs / DACs (db) Typ | 105 db, 110 db |
| Mounting Type | Surface Mount |
| Number of ADCs / DACs [custom] | 3 |
| Number of ADCs / DACs [custom] | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 48-QFN |
| Resolution (Bits) | 24 b |
| Sigma Delta | True |
| Supplier Device Package | 48-QFN-EP (6x6) |
| Type | HD, Audio |
| Voltage - Supply, Analog [Max] | 5.25 V |
| Voltage - Supply, Analog [Min] | 2.97 V |
| Voltage - Supply, Digital [Max] | 5.25 V |
| Voltage - Supply, Digital [Min] | 2.97 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 490 | $ 6.99 | |
Description
General part information
CS4207 Series
DAC1 (Headphone)101 dB Dynamic Range (A-wtd)-89 dB THD+N
101 dB Dynamic Range (A-wtd)
-89 dB THD+N
