SMTL2-UWD

Active

Bivar Inc.

LED UNI-COLOR WHITE 2-PIN PLCC T/R

Search across all available documentation for this part.

Active

Bivar Inc.

LED UNI-COLOR WHITE 2-PIN PLCC T/R

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Wavelength - Dominant	Configuration	Lens Transparency	Current - Test	Lens Color	Supplier Device Package	Height (Max) [Max]	Color	Voltage - Forward (Vf) (Typ)	Package / Case	Millicandela Rating	Viewing Angle	Height (Max) [Max] [z]	Wavelength - Dominant [custom]
Bivar Inc. SMTL2-URC	2.8 mm	3.2 mm	Surface Mount	622 nm	Standard	Clear	20 mA	Colorless	2-PLCC	1.9 mm	Red	2 V	2-PLCC	850 mcd	120 °
Bivar Inc. SMTL2-SUWD	2.8 mm	3.2 mm	Surface Mount		Standard	Diffused	20 mA	Yellow	2-PLCC		White	3.2 V	2-PLCC	2650 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-SBWC	2.8 mm	3.2 mm	Surface Mount	470 nm	Standard	Clear	20 mA	Colorless	2-PLCC		Blue	3.2 V	2-PLCC	285 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-GC	2.8 mm	3.2 mm	Surface Mount	570 nm	Standard	Clear	20 mA	Colorless	2-PLCC		Green	1.9 V	2-PLCC	40 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-RC	2.8 mm	3.2 mm	Surface Mount	640 nm	Standard	Clear	20 mA	Colorless	2-PLCC		Red	1.85 V	2-PLCC	36 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-HC	2.8 mm	3.2 mm	Surface Mount	627 nm	Standard	Clear	20 mA	Colorless	2-PLCC		Red	1.9 V	2-PLCC	28 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-OC	2.8 mm	3.2 mm	Surface Mount	605 nm	Standard	Clear	20 mA	Colorless	2-PLCC			1.9 V	2-PLCC	270 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-YC	2.8 mm	3.2 mm	Surface Mount		Standard	Clear	20 mA	Colorless	2-PLCC		Yellow	2 V	2-PLCC	16 mcd	120 °	2.1 mm	585 nm
Bivar Inc. SMTL2-UWD	2.8 mm	3.2 mm	Surface Mount		Standard	Diffused	20 mA	Yellow	2-PLCC		White	3.2 V	2-PLCC	1800 mcd	120 °	2.1 mm
Bivar Inc. SMTL2-SOC	2.8 mm	3.2 mm	Surface Mount	605 nm	Standard	Clear	20 mA	Colorless	2-PLCC			1.9 V	2-PLCC	800 mcd	120 °	2.1 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

White LED Indication - Discrete 3.2V 2-PLCC
