PXM6011/02P/CR/0507

Active

BULGIN LIMITED

CONNECTOR: CIRCULAR; PLUG; MALE; PIN: 2; 16A; 277V; W/O CONTACTS

Deep-Dive with AI

Search across all available documentation for this part.

Documents6000 Series UL Cert of Compliance 6000 Series CE Cert +3

PXM6011/02P/CR/0507

Active

BULGIN LIMITED

CONNECTOR: CIRCULAR; PLUG; MALE; PIN: 2; 16A; 277V; W/O CONTACTS

Deep-Dive with AI

Documents6000 Series UL Cert of Compliance 6000 Series CE Cert +3

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PXM6011/02P/CR/0507

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Type	Crimp and Solder Cup
Fastening Type	Push-Twist
Features	Backshell
Housing Color	Silver
Ingress Protection	IP69K, IP66, IP68, Dust Tight, Water Resistant, Waterproof
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	2
Operating Temperature [Max]	120 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shielding	Unshielded
Type	For Male Pins

PXM6011 Series

Part	Note	Contact Shape	Ingress Protection	Primary Material	Shielding	Connector Type	Mounting Type	Housing Color	Shell Material	Number of Positions	Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Fastening Type	Features	Orientation	Shell Finish	Number of Positions [custom]	Number of Positions [custom]	Number of Positions [custom]	Termination	Cable Opening [custom]	Cable Opening [custom]	Current Rating (Amps)	Contact Material	Color	Contact Finish - Mating	Voltage Rating	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [diameter]	Cable Opening [diameter]
BULGIN LIMITED PXM6011/02P/CR/0507	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Unshielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	2	For Male Pins	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel
BULGIN LIMITED PXM6011/03P/CR/0910	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Unshielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass		For Male Pins	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel	3	1	2
BULGIN LIMITED PXM6011/16S/CR/0709/SN	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	16	For Female Sockets	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel
BULGIN LIMITED PXM6011/03P/ST/0709/SN			Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Male Pins Plug	Free Hanging (In-Line)		Brass			-40 °C	120 °C		Push-Twist		Keyed	Nickel	3	1	2	Screw	0.276 in 0.354 in	7 mm 9 mm	16 A	Brass	Silver	Nickel	277 VAC/DC
BULGIN LIMITED PXM6011/03S/ST/0910/SN			Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Female Sockets Plug	Free Hanging (In-Line)		Brass			-40 °C	120 °C		Push-Twist		Keyed	Nickel	3	1	2	Screw			16 A	Brass	Silver	Nickel	277 VAC/DC	9 mm	0.394 in	10 mm	0.354 in
BULGIN LIMITED PXM6011/02P/CR/0405	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Unshielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	2	For Male Pins	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel
BULGIN LIMITED PXM6011/16P/CR/0507/SN	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	16	For Male Pins	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel
BULGIN LIMITED PXM6011/08S/CR/0405	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Unshielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	8	For Female Sockets	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel
BULGIN LIMITED PXM6011/02P/ST/0507/SN			Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Male Pins Plug	Free Hanging (In-Line)		Brass	2		-40 °C	120 °C		Push-Twist		Keyed	Nickel				Screw			16 A	Brass	Silver	Nickel	277 VAC/DC					0.197 in 0.276 in	5 mm 7 mm
BULGIN LIMITED PXM6011/08S/CR/0405/SN	Contacts Not Included	Circular	Dust Tight Water Resistant Waterproof IP66 IP68 IP69K	Metal	Shielded	Receptacle Housing	Free Hanging (In-Line)	Silver	Brass	8	For Female Sockets	-40 °C	120 °C	Crimp and Solder Cup	Push-Twist	Backshell	Keyed	Nickel

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	20	$ 45.83
Newark	Each	1	$ 61.49
TME	N/A	1	$ 6.16
		2	$ 5.92

Description

General part information

PXM6011 Series

2 (Power) Position Circular Connector Receptacle Housing Free Hanging (In-Line) Backshell
