A41-43-10L

Active

Signal Transformer

POWER TRANSFORMER 4000VRMS 43VA 8 TERMINAL WIRE LEAD FLANGE MOUNT

Search across all available documentation for this part.

Active

Signal Transformer

POWER TRANSFORMER 4000VRMS 43VA 8 TERMINAL WIRE LEAD FLANGE MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	A41-43-10L

Center Tap	False
Current - Output (Max) [Max] [custom]	4.3 A
Current - Output (Max) [Max] [custom]	8.6 A
Height - Seated (Max) [Max] [z]	68.2 mm
Mounting Type	Chassis Mount
Power - Max [Max]	43 VA
Primary Winding(s)	Dual
Secondary Winding(s)	Dual
Size / Dimension [x]	79.4 mm
Size / Dimension [y]	54.4 mm
Termination Style	Wire Leads
Type	Laminated Core
Voltage - Isolation	4000 Vrms
Voltage - Primary	115 V, 230 V
Voltage - Secondary (Full Load) [custom]	5 V
Voltage - Secondary (Full Load) [custom]	10 V
Weight	725.7 g
Weight	1.6 lbs

Power Transformers 50\60 Hz, Laminated Transformer w/ lead wires

Part	Voltage - Primary	Secondary Winding(s)	Primary Winding(s)	Termination Style	Current - Output (Max) [custom]	Current - Output (Max) [custom]	Voltage - Isolation	Voltage - Secondary (Full Load)	Size / Dimension [y]	Size / Dimension [x]	Weight	Weight	Type	Height - Seated (Max) [Max] [z]	Mounting Type	Power - Max [Max]	Current - Output (Max) [Max] [custom]	Current - Output (Max) [Max] [custom]	Voltage - Secondary (Full Load) [custom]	Voltage - Secondary (Full Load) [custom]	Current - Output (Max)
Signal Transformer A41-80-28	115 V 230 V	Dual	Dual	Quick Connect Solder	2.8 A	5.6 A	4000 Vrms	14 V 28 V	64.3 mm	63.5 mm	2.8 lbs	1.3 kg	Laminated Core	76.2 mm	Chassis Mount	80 VA
Signal Transformer A41-43-10L	115 V 230 V	Dual	Dual	Wire Leads			4000 Vrms		54.4 mm	79.4 mm	1.6 lbs	725.7 g	Laminated Core	68.2 mm	Chassis Mount	43 VA	4.3 A	8.6 A	5 V	10 V
Signal Transformer A41-25-515	115 V 230 V	Dual	Dual	Quick Connect Solder			4000 Vrms		54.4 mm	71.4 mm	1.3 lbs	589.7 g	Laminated Core	58.7 mm	Chassis Mount	25 VA			5 V	15 V	0.13 A 1.25 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Arrow	N/A	4	$ 20.29
		16	$ 19.91
Digikey	Box	40	$ 24.60
Sager	N/A	40	$ 21.66
		60	$ 20.29
		180	$ 17.81
		380	$ 16.49

General part information

Power Transformers 50\60 Hz, Laminated Transformer w/ lead wires

Technical documentation and resources
