901471132

Active

Molex

C-GRID III PC BOARD CONNECTOR, SINGLE ROW, VERTICAL, 32 CIRCUITS, TIN (SN) PLATING

Search across all available documentation for this part.

Active

Molex

C-GRID III PC BOARD CONNECTOR, SINGLE ROW, VERTICAL, 32 CIRCUITS, TIN (SN) PLATING

Technical Specifications

Parameters and characteristics for this part

Specification	901471132

null

C-Grid III PC Board Connector, Single Row, Vertical, 6 Circuits, Gold (Au) Plating

Part	Voltage Rating	Mounting Type	Insulation Color	Pitch - Mating	Pitch - Mating	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post	Contact Shape	Number of Rows	Termination	Contact Type	Insulation Height	Insulation Height	Contact Material	Contact Finish - Post	Insulation Material	Fastening Type	Number of Positions Loaded	Applications	Current Rating (Amps)	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Connector Type	Number of Positions
Molex 901471214
Molex 0901471103	350 V	Through Hole	Black	0.1 in	2.54 mm	105 ░C	-55 °C	40 µin	1.02 µm	0.114 in	2.9 mm	Square	1	Solder	Female Socket	0.335 "	8.51 mm	Phosphor Bronze	Tin	Polyester Glass Filled	Push-Pull	All	Automotive General Purpose Lighting Medical Telecommunications	3 A	1.02 Ám	40 Áin	Receptacle
Molex 901471132
Molex 901471204
Molex 0901471108	350 V	Through Hole	Black	0.1 in	2.54 mm	105 ░C	-55 °C	40 µin	1.02 µm	0.114 in	2.9 mm	Square	1	Solder	Female Socket	0.335 "	8.51 mm	Phosphor Bronze	Tin	Polyester Glass Filled	Push-Pull	All	Automotive General Purpose Lighting Medical Telecommunications	3 A	1.02 Ám	40 Áin	Receptacle	8

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

C-Grid III PC Board Connector, Single Row, Vertical, 6 Circuits, Gold (Au) Plating
