Technical Specifications
Parameters and characteristics for this part
| Specification | PML50SYFVW |
|---|---|
| Ingress Protection | IP67 |
| Lamp Color | Yellow |
| Lens Color | Yellow |
| Lens Size [diameter] | 17.8 mm |
| Lens Style | Round with Domed Top |
| Lens Transparency | Clear |
| Millicandela Rating | 970 mcd |
| Panel Cutout Dimensions | 17.53 mm |
| Panel Cutout Dimensions | 0.69 in |
| Panel Cutout Shape | Round |
| Ratings | DC |
| Termination Style | Wire Leads - 5.5" (139.70mm) |
| Type | LED |
| Voltage [Max] | 28 V |
| Voltage [Min] | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 17.01 | |
| 10 | $ 12.83 | |||
| 100 | $ 10.78 | |||
| 500 | $ 9.90 | |||
| 1000 | $ 9.35 | |||
Description
General part information
PML50 Series
LED Panel Indicator Yellow Clear 5V ~ 28V 20mA Wire Leads - 5.5" (139.70mm)
