09140044713

Active

HARTING Technology Group

HAN SC FIBER MODULE FEMALE INSERT WITH METAL FERRULES

Search across all available documentation for this part.

Active

HARTING Technology Group

HAN SC FIBER MODULE FEMALE INSERT WITH METAL FERRULES

Technical Specifications

Parameters and characteristics for this part

Specification	09140044713

Color	Gray
Connector Type	Module, Fiber Optic - SC
Contact Type	Fiber Optic, SC
Gender	Female
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	4
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Termination Style	Crimp

Part	Gender	Termination Style	Material Flammability Rating	Contact Type	Number of Positions	Housing Material	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Color	Current Rating (Amps)	Voltage Rating
HARTING Technology Group 09140044501	Male	Crimp and Solder	UL94 V-0	Han-Modular®	4	Polycarbonate (PC)	Module without Contacts	125 °C	-40 °C	Gray
HARTING Technology Group 09140044711	Female		UL94 V-0	Fiber Optic SC	4	Polycarbonate (PC)	Module without Contacts	85 °C	-40 °C	Gray
HARTING Technology Group 09140044514
HARTING Technology Group 09140044513	Female	Crimp and Solder	UL94 V-0	Han-Modular®	4	Polycarbonate (PC)	Module without Contacts	125 °C	-40 °C	Gray	1.5 A	50 V
HARTING Technology Group 09140044701	Male		UL94 V-0	Fiber Optic SC	4	Polycarbonate (PC)	Module without Contacts	85 °C	-40 °C	Gray
HARTING Technology Group 09140044713	Female	Crimp	UL94 V-0	Fiber Optic SC	4	Polycarbonate (PC)	Module Fiber Optic - SC	85 °C	-40 °C	Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Female Module, Fiber Optic - SC Gray 4 Position Crimp
