Technical Specifications
Parameters and characteristics for this part
| Specification | N3030 2 |
|---|---|
| Actuator Diameter [diameter] | 0.422 in |
| Actuator Diameter [diameter] | 10.72 mm |
| Color | Gray |
| For Use With/Related Products | Multiple Series |
| Ingress Protection | IP66/IP68 |
| Material | Silicone Rubber |
| Mounting Feature | Front of Panel |
| Operating Temperature [Max] | 204 °C |
| Operating Temperature [Min] | -70 °C |
| Size / Dimension [z] | 0.547 in |
| Size / Dimension [z] | 13.89 mm |
| Thread Size | 15/32-32 NS-2B |
| Type | Pushbutton, Full Boot |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 2.93 | |
| 10 | $ 2.78 | |||
| 25 | $ 2.71 | |||
| 50 | $ 2.67 | |||
| 100 | $ 2.64 | |||
| 250 | $ 2.60 | |||
| 500 | $ 2.56 | |||
| 1000 | $ 2.16 | |||
Description
General part information
N3030 Series
PUSHBUTTON FULL BOOT GRAY
