UF90DPB23-H1S2A
ActiveMechatronics Bearing Group
BLOWER 120X37MM 230VAC
Deep-Dive with AI
Search across all available documentation for this part.
UF90DPB23-H1S2A
ActiveMechatronics Bearing Group
BLOWER 120X37MM 230VAC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | UF90DPB23-H1S2A |
|---|---|
| Air Flow | 0.588 mł/min |
| Air Flow | 21 CFM |
| Approval Agency | CE, cUL, TUV, UL |
| Bearing Type | Ball |
| Current Rating (Amps) | 100 mA |
| Fan Type | Blower, Centrifugal |
| Features | Thermal Overload Protector (TOP) |
| Material - Blade | Polyamide (PA), Nylon |
| Material - Frame | Aluminum |
| Noise | 51 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 18 W |
| RPM | 2700 RPM |
| Size / Dimension [x] | 120 mm |
| Size / Dimension [y] | 120 mm |
| Static Pressure | 124.5 Pa |
| Static Pressure | 0.5 in H2O |
| Termination | 2 Wire Leads |
| Voltage - Rated | 230 VAC |
| Weight | 1.4 lbs |
| Weight | 635 g |
| Width [x] | 37.2 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 43.16 | |
| 10 | $ 39.42 | |||
| 40 | $ 37.92 | |||
| 80 | $ 35.43 | |||
| 120 | $ 32.68 | |||
| 280 | $ 32.18 | |||
Description
General part information
UF90D Series
Fan Blower, Centrifugal 230VAC Square - 120mm L x 120mm H Ball 21.0 CFM (0.588mł/min) 2 Wire Leads
