OKI-78SR-3.3/1.5-W36E-C
LTBMurata Power Solutions Inc.
MODULE DC-DC 12VIN 1-OUT 3.3V 1.5A 4.95W 3-PIN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OKI-78SR-3.3/1.5-W36E-C
LTBMurata Power Solutions Inc.
MODULE DC-DC 12VIN 1-OUT 3.3V 1.5A 4.95W 3-PIN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | OKI-78SR-3.3/1.5-W36E-C |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1.5 A |
| Efficiency | 85.5 % |
| Features | SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 3-SIP Module |
| Power (Watts) | 5 W |
| Size / Dimension [x] | 11.9 mm |
| Size / Dimension [x] | 0.47 in |
| Size / Dimension [y] | 10 mm |
| Size / Dimension [y] | 0.39 " |
| Size / Dimension [z] | 0.69 " |
| Size / Dimension [z] | 17.6 mm |
| Type | Linear Regulator Replacement |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 7 V |
| Voltage - Output 1 | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 6.81 | |
| 5 | $ 6.76 | |||
| 10 | $ 6.70 | |||
| 25 | $ 6.61 | |||
| 50 | $ 6.41 | |||
| 100 | $ 5.98 | |||
| 250 | $ 5.75 | |||
Description
General part information
OKI-78SR Series
Non-Isolated DC/DC Converters 4.95W 12VIN 3.3VOUT 1.5A DC/DC
