AME3-24SCJZ

Unknown

aimtec

24V 125MA 85VAC~264VAC 3W 78% DIP,37X24.5MM AC-DC POWER MODULES ROHS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AME3-24SCJZ

Unknown

aimtec

24V 125MA 85VAC~264VAC 3W 78% DIP,37X24.5MM AC-DC POWER MODULES ROHS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AME3-24SCJZ

Applications	ITE (Commercial)
Current - Output (Max) [Max]	125 mA
Efficiency	78 %
Features	Universal Input
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Package / Case	26-DIP Module, 5 Leads
Power (Watts)	3 W
Size / Dimension [x]	1.46 in
Size / Dimension [x]	37 mm
Size / Dimension [y]	24.5 mm
Size / Dimension [y]	0.96 in
Size / Dimension [z]	0.71 in
Size / Dimension [z]	18 mm
Type	Enclosed
Voltage - Input [Max]	264 VAC, 370 VDC
Voltage - Input [Min]	100 V, 85 VAC
Voltage - Output 1	24 V

AME3 Series

Part	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Load Regulation	Number of Outputs	Line Regulation	Power (Watts)	Type	Voltage - Input [Min]	Voltage - Input [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Current - Output (Max) [Max]	Applications	Features	Package / Case	Package / Case	Efficiency	Voltage - Output 1	Weight	Weight	Size / Dimension [z]	Size / Dimension [y]
aimtec AME3-24SHAVZ	CE	70 °C	-25 °C	Through Hole	0.5 %	1	0.3 %	3 W	Enclosed	85 VAC 120 VDC	264 VAC 373 VDC	1.27 in	1.07 in	27.3 mm	32.3 mm	21.8 mm	0.86 in	125 mA	Household Appliances ITE (Commercial)	Universal Input	4 Lead	9-DIP Module	75 %	24 V	0.055 lb	25 g
aimtec AME3-24SAZ	CE cURus FCC	80 ¯C	-40 °C	Through Hole	5 %	1	3 %	3 W	Enclosed	90 VAC 130 VDC	305 VAC 430 VDC	1.4 in	0.92 "		35.6 mm		0.76 "	125 mA	ITE (Commercial)			4-DIP Module	81 %	24 V			19.3 mm	23.3 mm
aimtec AME3-05SHAVZ	CE	70 °C	-40 °C	Through Hole	0.5 %	1	0.3 %	3 W	Enclosed			1.27 in	1.07 in	27.3 mm	32.3 mm	21.8 mm	0.85 "	600 mA	Household Appliances ITE (Commercial)	Universal Input	4 Lead	9-DIP Module	72 %	5 V	0.055 lb	25 g
aimtec AME3-24SBAZ	CE cURus FCC	80 ¯C	-40 °C	Through Hole	5 %	1	3 %	3 W	Enclosed	90 VAC 130 VDC	528 VAC 745 VDC	1.4 in	0.92 "		35.6 mm		0.76 "	125 mA	ITE (Commercial)			4-DIP Module	71 %	24 V			19.3 mm	23.3 mm
aimtec AME3-24SCJZ		70 °C	-25 °C	Through Hole		1		3 W	Enclosed	85 VAC 100 V	264 VAC 370 VDC	1.46 in	0.96 in	24.5 mm	37 mm	18 mm	0.71 in	125 mA	ITE (Commercial)	Universal Input		26-DIP Module 5 Leads	78 %	24 V
aimtec AME3-24SBJZ				Through Hole	2.5 %	1	1.5 %	3 W	Enclosed	90 VAC 100 V	528 VAC 745 VDC	2 in	25.4 mm	25.4 mm	50.8 mm	15.2 mm	0.6 "	125 mA	ITE (Commercial)			4-DIP Module	76 %	24 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 23.87
		10	$ 23.56
		15	$ 22.85
		25	$ 22.17
		50	$ 21.72
		100	$ 21.29
		200	$ 20.86
		500	$ 20.03
		1000	$ 18.63
LCSC	Piece	1	$ 49.30
		200	$ 19.67
		500	$ 19.01
		1000	$ 18.69

Description

General part information

AME3 Series

Enclosed AC DC Converters 1 Output 24V 125mA 85 ~ 264 VAC, 100 ~ 370 VDC Input

Documents

Technical documentation and resources
