19302060291 - 19302060291

19302060291

Active
HARTING Technology Group

HOOD, SIDE ENTRY, 6B, M25, 1 LEVER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet19302060291 Prod Declaration Cert+1
19302060291 - 19302060291

19302060291

Active
HARTING Technology Group

HOOD, SIDE ENTRY, 6B, M25, 1 LEVER

Deep-Dive with AI

DocumentsDatasheet19302060291 Prod Declaration Cert+1

Technical Specifications

Parameters and characteristics for this part

Specification19302060291
Connector TypeBase - Box Mount
FeaturesFeed Through
Housing ColorGray
Housing FinishPowder Coated
Housing MaterialDie Cast, Aluminum
Ingress ProtectionIP65 - Dust Tight, Water Resistant
Lock LocationLocking Clip (1) on Base Bottom
Operating Temperature [Max]125 °C
Operating Temperature [Min]-40 °C
Size6B
Size / Dimension [x]3.228 in
Size / Dimension [x]82 mm
Size / Dimension [y]2.244 "
Size / Dimension [y]57 mm
Size / Dimension [z]2.906 "
Size / Dimension [z]73.8 mm
StyleSide Entry, Dual
Thread SizeM25

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 43.48
10$ 38.07
25$ 36.43
50$ 35.25
100$ 34.08
250$ 32.20
NewarkEach 1$ 44.71
5$ 41.77
10$ 38.75
25$ 35.73
50$ 33.61
100$ 31.99

Description

General part information

19302060 Series

Base - Box Mount Connector Side Entry, Dual M25 6B IP65 - Dust Tight, Water Resistant
