AM1DU-0512SZ
Unknownaimtec
MODULE DC-DC 5VIN 1-OUT 12V 0.083A 1W 4-PIN SIP MODULE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1DU-0512SZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 83 mA |
| Efficiency | 79 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 90 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 7-SIP Module, 4 Leads |
| Power (Watts) | 996 mW |
| Size / Dimension [x] | 19.5 mm |
| Size / Dimension [x] | 0.77 in |
| Size / Dimension [y] | 0.28 in |
| Size / Dimension [y] | 7.2 mm |
| Size / Dimension [z] | 0.39 in |
| Size / Dimension [z] | 10 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 9 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 12.81 | |
| 10 | $ 11.26 | |||
| 25 | $ 10.69 | |||
| 50 | $ 10.29 | |||
| 100 | $ 9.89 | |||
| 250 | $ 9.40 | |||
| 500 | $ 9.04 | |||
| 1000 | $ 8.70 | |||
Description
General part information
AM1DU Series
Isolated Module DC DC Converter 1 Output 12V 83mA 4.5V - 9V Input
