Parameters and characteristics for this part
| Specification | 2839415 |
|---|---|
| Accessory Type | Base |
| For Use With/Related Products | PT, Surge Protector |
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
General part information
Pluggable Terminal Blocks 10 Pos 5mm pitch Plug 26-14 AWG Screw
Technical documentation and resources
Pluggable Terminal Blocks 10 Pos 5mm pitch Plug 26-14 AWG Screw
| Part | For Use With/Related Products | Accessory Type | Number of Positions | Termination Style | Wire Gauge or Range - mm² [Max] | Wire Gauge or Range - mm² [Min] | Type | Color | Terminal - Width [y] | Material Flammability Rating | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Number of Levels | Material - Insulation | Stripping Length [x] | Housing Color | Height (Max) [Max] | Height (Max) [Max] | Stripping Length | Length [x] | Length [x] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact | PT Surge Protector | Base | ||||||||||||||||||||
Phoenix Contact | 2 | Push In Spring | 10 mm² | 0.5 mm² | Ground Earth | Green Yellow | 8.2 mm | UL94 V-0 | 8 AWG | 20 AWG | 1 | Nylon Polyamide (PA) | 12 mm | |||||||||
Phoenix Contact | Plug Receptacles Push In Spring | 1.5 mm² | 0.14 mm² | Plug Connection | 3.5 mm | UL94 V-0 | 14 AWG | 26 AWG | 1 | Nylon Polyamide (PA) | Green Yellow | 39.5 mm | 1.555 in | 8 mm | 55 mm | 2.165 in | DIN Rail |
