TEL 8-4815WI
ActiveTraco Power
DC DC CONVERTER 24V 8W
Deep-Dive with AI
Search across all available documentation for this part.
TEL 8-4815WI
ActiveTraco Power
DC DC CONVERTER 24V 8W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | TEL 8-4815WI |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 335 mA |
| Efficiency | 86 % |
| Features | SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 80 ¯C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 16-DIP Module |
| Package / Case | 6 Leads |
| Power (Watts) | 8 W |
| Size / Dimension [x] | 0.95 in |
| Size / Dimension [x] | 24.1 mm |
| Size / Dimension [y] | 14 mm |
| Size / Dimension [y] | 0.55 in |
| Size / Dimension [z] | 8.5 mm |
| Size / Dimension [z] | 0.33 in |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 25.17 | |
| 10 | $ 23.13 | |||
| 25 | $ 22.37 | |||
| 50 | $ 21.81 | |||
| 100 | $ 21.26 | |||
| 250 | $ 20.56 | |||
| 500 | $ 18.09 | |||
Description
General part information
TEL 8 Series
Isolated Module DC DC Converter 1 Output 24V 335mA 18V - 75V Input
