TL-N20ME1

Active

Omron Electronics Inc-EMC Div

SENSOR PROX INDUCT 20MM IP67 MOD

Search across all available documentation for this part.

Active

Omron Electronics Inc-EMC Div

SENSOR PROX INDUCT 20MM IP67 MOD

Technical Specifications

Parameters and characteristics for this part

Part	Termination Style	Sensing Distance	Sensing Distance	Indicator [custom]	Output Type	Shielding	Material - Body	Voltage - Supply [Max]	Voltage - Supply [Min]	Package / Case	Response Frequency	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Sensor Type
Omron Electronics Inc-EMC Div TL-N20ME2	Cable Leads	0.787 in	20 mm	LED	NPN-NC 3-Wire	Unshielded	Plastic	30 VDC	10 VDC	Module	40 Hz	IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20ME1 5M	Cable Leads	0.787 in	20 mm	LED	NPN-NO 3-Wire	Unshielded	Plastic	30 VDC	10 VDC	Module	40 Hz	IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20ME15 2M	Cable Leads	0.787 in	20 mm	LED	NPN-NO 3-Wire	Unshielded	Plastic	30 VDC	10 VDC	Module		IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20MD2	Cable Leads	0.787 in	20 mm	LED	NPN-NC 2-Wire	Unshielded	Plastic	30 VDC	10 VDC	Module	300 Hz	IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20ME1	Cable Leads	0.787 in	20 mm	LED	NPN-NO 3-Wire	Unshielded	Plastic	30 VDC	10 VDC	Module	40 Hz	IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20MD1	Cable Leads	0.787 in	20 mm	LED	2-Wire NPN-NO	Unshielded	Plastic	30 VDC	10 VDC	Module	300 Hz	IP67	70 °C	-25 °C	Inductive
Omron Electronics Inc-EMC Div TL-N20MY2	Cable Leads	0.787 in	20 mm	LED	SCR-NC 2-Wire	Unshielded	Plastic	250 VAC	90 VAC	Module	10 Hz	IP67	70 °C	-25 °C	Inductive

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

SENSOR PROX INDUCT 20MM IP67 MOD
