C90-3106F10SL-3P

Active

Harwin Inc.

CIRCULAR CONNECTOR, CABLE MOUNT PLUG, 3 CONTACTS, SOLDER PIN, ALUMINUM ALLOY BODY

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet C90 Circular Catalog +3

C90-3106F10SL-3P

Active

Harwin Inc.

CIRCULAR CONNECTOR, CABLE MOUNT PLUG, 3 CONTACTS, SOLDER PIN, ALUMINUM ALLOY BODY

Deep-Dive with AI

DocumentsDatasheet C90 Circular Catalog +3

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	C90-3106F10SL-3P

Applications	Industrial, Automotive
Backshell Material, Plating	Black Zinc Cobalt, Aluminum Alloy
Cable Opening [diameter]	7.14 mm
Cable Opening [diameter]	0.281 in
Color	Black
Connector Type	Plug, Male Pins
Contact Finish - Mating	Silver
Contact Material	Copper Alloy
Current Rating (Amps)	13 A
Features	Cable Clamp, Coupling Nut, Backshell
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Synthetic Rubber
Mounting Type	Free Hanging (In-Line)
Number of Positions	3
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Black Zinc Cobalt Alloy
Shell Material	Aluminum Alloy
Shell Size - Insert	10SL-3
Shielding	Unshielded
Voltage Rating	700 VDC, 500 VAC

C90-3106F Series

Part	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Orientation	Shell Size - Insert	Primary Material	Mounting Type	Contact Finish - Mating	Shell Material	Insert Material	Contact Material	Shell Finish	Connector Type	Cable Opening [diameter]	Cable Opening [diameter]	Backshell Material, Plating	Current Rating (Amps)	Number of Positions	Ingress Protection	Features	Shielding	Voltage Rating	Color	Cable Opening [custom]	Cable Opening [custom]
Harwin Inc. C90-3106F12S-3S	-55 °C	125 °C	Automotive Industrial	Keyed	12S-3	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Female Sockets Plug	7.14 mm	0.281 in	Aluminum Alloy Black Zinc Cobalt	13 A	2	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	500 VAC 700 VDC	Black
Harwin Inc. C90-3106F10SL-3P	-55 °C	125 °C	Automotive Industrial	Keyed	10SL-3	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Male Pins Plug	7.14 mm	0.281 in	Aluminum Alloy Black Zinc Cobalt	13 A	3	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	500 VAC 700 VDC	Black
Harwin Inc. C90-3106F14S-2S	-55 °C	125 °C	Automotive Industrial	Keyed	14S-2	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Female Sockets Plug			Aluminum Alloy Black Zinc Cobalt	13 A	4	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	200 VAC 250 VDC	Black	10.3 mm	0.406 in
Harwin Inc. C90-3106F10SL-3S	-55 °C	125 °C	Automotive Industrial	Keyed	10SL-3	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Female Sockets Plug	7.14 mm	0.281 in	Aluminum Alloy Black Zinc Cobalt	13 A	3	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	500 VAC 700 VDC	Black
Harwin Inc. C90-3106F10SL-4P	-55 °C	125 °C	Automotive Industrial	Keyed	10SL-4	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Male Pins Plug	7.14 mm	0.281 in	Aluminum Alloy Black Zinc Cobalt	13 A	2	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	500 VAC 700 VDC	Black
Harwin Inc. C90-3106F14S-6P	-55 °C	125 °C	Automotive Industrial	Keyed	14S-6	Metal	Free Hanging (In-Line)	Silver	Aluminum Alloy	Synthetic Rubber	Copper Alloy	Black Zinc Cobalt Alloy	Male Pins Plug			Aluminum Alloy Black Zinc Cobalt	13 A	6	IP67 - Dust Tight Waterproof	Backshell Cable Clamp Coupling Nut	Unshielded	200 VAC 250 VDC	Black	10.3 mm	0.406 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 23.06
		10	$ 17.77
		25	$ 16.09
		50	$ 14.95
		100	$ 13.92
		250	$ 12.70
		500	$ 11.88
Newark	Each	1	$ 18.87
		10	$ 16.04
		25	$ 15.03
		50	$ 14.32
		100	$ 13.63
		250	$ 12.78

Description

General part information

C90-3106F Series

3 (Power) Position Circular Connector Plug, Male Pins Solder Cup
