9WF0624H7D01

Active

Sanyo Denki America Inc.

FAN AXIAL 60X15MM 24VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsNumbering System Oil Proof Fan Rotor Balancing +1

9WF0624H7D01

Active

Sanyo Denki America Inc.

FAN AXIAL 60X15MM 24VDC WIRE

Deep-Dive with AI

DocumentsNumbering System Oil Proof Fan Rotor Balancing +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9WF0624H7D01

Approval Agency	CSA, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	120 mA
Fan Type	Tubeaxial
Features	Locked Rotor Sensor
Ingress Protection	Oil Resistant
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	44 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
Power (Watts)	2.88 W
RPM	6800 RPM
Size / Dimension [x]	60 mm
Size / Dimension [y]	60 mm
Static Pressure	94.6 Pa
Static Pressure	0.38 in H2O
Termination	3 Wire Leads
Voltage - Rated	24 VDC
Weight	62.14 g
Weight	0.137 lb
Width [x]	15 mm

9WF0624 Series

Part	Bearing Type	Noise	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Lifetime @ Temp.	Material - Frame	Fan Type	RPM	Features	Power (Watts)	Static Pressure	Static Pressure	Ingress Protection	Current Rating (Amps)	Voltage Range [Max]	Voltage Range [Min]	Width [y]	Air Flow	Air Flow	Termination	Material - Blade	Size / Dimension [x]	Size / Dimension [y]	Approval Agency	Weight	Weight	Voltage - Rated	Width [x]
Sanyo Denki America Inc. 9WF0624H601	Ball	42 dB	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	Plastic	Tubeaxial	6600 RPM	Speed Sensor (Tach)	3.6 W	112.1 Pa	0.45 in H2O	Oil Resistant	150 mA	27.6 VDC	12 VDC	20 mm	24.3 CFM	0.68 m³/min	3 Wire Leads	Plastic	60 mm	60 mm	CSA TUV UL	0.177 lb	80.29 g	24 VDC
Sanyo Denki America Inc. 9WF0624H6D01	Ball	42 dB	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	Plastic	Tubeaxial	6600 RPM	Locked Rotor Sensor	3.6 W	112.1 Pa	0.45 in H2O	Oil Resistant	150 mA	27.6 VDC	12 VDC	20 mm	24.3 CFM	0.68 m³/min	3 Wire Leads	Plastic	60 mm	60 mm	CSA TUV UL	0.177 lb	80.29 g	24 VDC
Sanyo Denki America Inc. 9WF0624H4D01	Ball	41 dB	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	Plastic	Tubeaxial	6500 RPM	Locked Rotor Sensor	3.6 W	94.6 Pa	0.38 in H2O	Oil Resistant	150 mA			25 mm	23.6 CFM	0.661 m³/min	3 Wire Leads	Plastic	60 mm	60 mm	CSA TUV UL	0.243 lb	110.22 g	24 VDC
Sanyo Denki America Inc. 9WF0624H401	Ball	41 dB	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	Plastic	Tubeaxial	6500 RPM	Speed Sensor (Tach)	3.6 W	94.6 Pa	0.38 in H2O	Oil Resistant	150 mA			25 mm	23.6 CFM	0.661 m³/min	3 Wire Leads	Plastic	60 mm	60 mm	CSA TUV UL	0.243 lb	110.22 g	24 VDC
Sanyo Denki America Inc. 9WF0624H7D01	Ball	44 dB	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	Plastic	Tubeaxial	6800 RPM	Locked Rotor Sensor	2.88 W	94.6 Pa	0.38 in H2O	Oil Resistant	120 mA						3 Wire Leads	Plastic	60 mm	60 mm	CSA TUV UL	0.137 lb	62.14 g	24 VDC	15 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 22.34
		10	$ 20.40
		25	$ 19.62
		50	$ 18.33
		100	$ 16.91
		300	$ 16.65
		500	$ 16.53

Description

General part information

9WF0624 Series

Fan Tubeaxial 24VDC Square - 60mm L x 60mm H Ball 18.3 CFM (0.512mł/min) 3 Wire Leads
