PS2P-LIN-CE-M002-1A0-L0000-ELS120-05
ActiveAmphenol Piher Sensing Systems
SENSOR LINEAR 12MM WIRE LEADS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PS2P-LIN-CE-M002-1A0-L0000-ELS120-05 |
|---|---|
| Actuator Type | External Magnet, Included |
| For Measuring | Linear Position |
| Linear Range [Max] | 12 mm |
| Linear Range [Max] | 0.47 in |
| Linear Range [Min] | 0 in |
| Linear Range [Min] | 0 mm |
| Linearity | 1 % |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Output | Analog Voltage |
| Package / Case | Box with Wire Leads |
| Technology | Hall Effect |
| Termination Style | Wire Leads |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 67.50 | |
| 5 | $ 56.93 | |||
| 10 | $ 52.91 | |||
| 25 | $ 48.03 | |||
| 50 | $ 44.64 | |||
| 100 | $ 41.49 | |||
Description
General part information
PS2P Series
Hall Effect Sensor Linear Position External Magnet, Included Wire Leads
