M80-263F104-00-00
ActiveHarwin Inc.
HOUSING CONNECTOR, RCPT, 4POS, 4MM ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
M80-263F104-00-00
ActiveHarwin Inc.
HOUSING CONNECTOR, RCPT, 4POS, 4MM ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M80-263F104-00-00 |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp and Solder |
| Contact Type | Female Socket |
| Features | Polarizing Key, Jackscrews |
| Insulation Material | Polyphenylene Sulfide (PPS) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 4 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Pitch [x] | 4 mm |
| Pitch [x] | 0.157 in |
M80-263 Series
| Part | Pitch [x] | Pitch [x] | Note | Number of Positions | Contact Type | Connector Type | Number of Rows | Features | Color | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Contact Termination | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Harwin Inc. | 4 mm | 0.157 in | Contacts Not Included | 3 | Female Socket | Receptacle | 1 | Jackscrews Polarizing Key | Black | -55 °C | 125 °C | Polyphenylene Sulfide (PPS) | Crimp and Solder | |
Harwin Inc. | 4 mm | 0.157 in | Contacts Not Included | 4 | Female Socket | Receptacle | Jackscrews Polarizing Key | Black | -55 °C | 125 °C | Polyphenylene Sulfide (PPS) | Crimp and Solder | Free Hanging (In-Line) | |
Harwin Inc. | 4 mm | 0.157 in | Contacts Not Included | 2 | Female Socket | Receptacle | 1 | Jackscrews Polarizing Key | Black | -55 °C | 125 °C | Polyphenylene Sulfide (PPS) | Crimp and Solder | |
Harwin Inc. | 4 mm | 0.157 in | Contacts Not Included | 3 | Female Socket | Receptacle | 1 | Jackscrews Polarizing Key | Black | -55 °C | 125 °C | Polyphenylene Sulfide (PPS) | Crimp and Solder | Free Hanging (In-Line) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
M80-263 Series
4 (Coax or Power) Rectangular Connectors - Housings Receptacle Black 0.157" (4.00mm)
