RFABSMAJSMAJ
ActiveBULGIN LIMITED
RF / COAXIAL ADAPTER, SMA, JACK, SMA, JACK, RIGHT ANGLE ADAPTER, 50 OHM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | RFABSMAJSMAJ |
|---|---|
| Adapter Series | SMA to SMA |
| Adapter Type | Jack to Jack |
| Body Material | Stainless Steel |
| Center Contact Material | Beryllium Copper |
| Center Gender | Female to Female |
| Conversion Type | Same Series |
| Convert From (Adapter End) | Female Socket, SMA Jack |
| Convert To (Adapter End) | SMA Jack, Female Socket |
| Dielectric Material | Polyetherimide (PEI), Polytetrafluoroethylene (PTFE) |
| Frequency - Max [Max] | 26.5 GHz |
| Impedance | 50 Ohms |
| Mating Cycles | 500 |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Operating Temperature [Max] | 165 °C |
| Operating Temperature [Min] | -65 ░C |
| Style | Right Angle |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
RFABSMA Series
Adapter Coaxial Connector SMA Jack, Female Socket To SMA Jack, Female Socket 50 Ohms
