RFABSMAPSMAP

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, SMA, PLUG, SMA, PLUG, RIGHT ANGLE ADAPTER, 50 OHM

Search across all available documentation for this part.

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, SMA, PLUG, SMA, PLUG, RIGHT ANGLE ADAPTER, 50 OHM

Technical Specifications

Parameters and characteristics for this part

Specification	RFABSMAPSMAP

Adapter Series	SMA to SMA
Adapter Type	Plug to Plug
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Gender	Male to Male
Conversion Type	Same Series
Convert From (Adapter End)	SMA Plug, Male Pin
Convert To (Adapter End)	SMA Plug, Male Pin
Dielectric Material	Polyetherimide (PEI), Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	26.5 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Type	Free Hanging (In-Line), Right Angle
Operating Temperature [Max]	165 °C
Operating Temperature [Min]	-65 ░C
Style	Right Angle

Part	Body Material	Frequency - Max [Max]	Conversion Type	Convert To (Adapter End)	Convert From (Adapter End)	Style	Center Contact Material	Adapter Type	Impedance	Mating Cycles	Center Gender	Dielectric Material	Adapter Series	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
BULGIN LIMITED RFABSMAJSMAJ	Stainless Steel	26.5 GHz	Same Series	Female Socket SMA Jack	Female Socket SMA Jack	Right Angle	Beryllium Copper	Jack to Jack	50 Ohms	500	Female to Female	Polyetherimide (PEI) Polytetrafluoroethylene (PTFE)	SMA to SMA	-65 ░C	165 °C	Free Hanging (In-Line) Right Angle
BULGIN LIMITED RFABSMAPSMAP	Stainless Steel	26.5 GHz	Same Series	Male Pin SMA Plug	SMA Plug Male Pin	Right Angle	Beryllium Copper	Plug to Plug	50 Ohms	500	Male to Male	Polyetherimide (PEI) Polytetrafluoroethylene (PTFE)	SMA to SMA	-65 ░C	165 °C	Free Hanging (In-Line) Right Angle

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 111.14
Newark	Each	1	$ 160.39
		100	$ 157.17

General part information

Adapter Coaxial Connector SMA Plug, Male Pin To SMA Plug, Male Pin 50 Ohms
