THM 20-4813WI

Active

Traco Power

DC DC CONVERTER 15V 20W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

THM 20-4813WI

Active

Traco Power

DC DC CONVERTER 15V 20W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	THM 20-4813WI

Applications	Medical
Current - Output (Max) [Max]	1.33 A
Efficiency	88 %
Features	OTP, SCP, OVP, OCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	80 ¯C
Operating Temperature [Min]	-40 °C
Package / Case	5-DIP Module
Power (Watts)	20 W
Size / Dimension [x]	40.6 mm
Size / Dimension [x]	1.6 "
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	10.2 mm
Size / Dimension [z]	0.4 "
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	5000 V
Voltage - Output 1	15 V

THM 20 Series

Part	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Type	Applications	Mounting Type	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Power (Watts)	Package / Case	Number of Outputs	Voltage - Isolation	Efficiency	Features	Voltage - Output 1	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2	Current - Output (Max) [Max]	Current - Output (Max)
Traco Power THM 20-2412	36 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	1.67 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	1	5000 V	90 %	OCP OTP OVP SCP	12 V
Traco Power THM 20-4823	75 V	36 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole		10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	2	5000 V	88 %	OCP OTP OVP SCP	15 V	667 mA	667 mA	-15 V
Traco Power THM 20-1221	18 V	9 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	2 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	2	5000 V	86 %	OCP OTP OVP SCP	5 V			-5 V	2 A
Traco Power THM 20-4813WI	75 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	1.33 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	1	5000 V	88 %	OCP OTP OVP SCP	15 V
Traco Power THM 20-4815	75 V	36 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	833 mA	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	1	5000 V	88.5 %	OCP OTP OVP SCP	24 V
Traco Power THM 20-4812WI	75 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	1.67 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	1	5000 V	88 %	OCP OTP OVP SCP	12 V
Traco Power THM 20-2421WI	36 V	9 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	2 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	2	5000 V	86 %	OCP OTP OVP SCP	5 V			-5 V	2 A
Traco Power THM 20-4815WI	75 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	833 mA	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	1	5000 V	88.5 %	OCP OTP OVP SCP	24 V
Traco Power THM 20-2421	36 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole	2 A	10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	2	5000 V	86 %	OCP OTP OVP SCP	5 V			-5 V	2 A
Traco Power THM 20-2422	36 V	18 V	-40 °C	80 ¯C	Isolated Module	Medical	Through Hole		10.2 mm	40.6 mm	1.6 "	25.4 mm	25.4 mm	0.4 "	20 W	5-DIP Module	2	5000 V	90 %	OCP OTP OVP SCP	12 V	833 mA		-12 V		833 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 79.25
		10	$ 72.84
		25	$ 70.44
		50	$ 68.67
		100	$ 66.95
		250	$ 59.34

Description

General part information

THM 20 Series

Isolated Module DC DC Converter 1 Output 15V 1.33A 18V - 75V Input
