0022272141

Active

Molex

CONN HEADER VERT 14POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

0022272141

Active

Molex

CONN HEADER VERT 14POS 2.54MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	0022272141

Applications	Medical, General Purpose, Automotive, Telecommunications
Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	2.54 çm
Contact Finish Thickness - Mating	100 çin
Contact Finish Thickness - Post	2.54 µm
Contact Finish Thickness - Post	100 µin
Contact Length - Mating	7.49 mm
Contact Length - Mating	0.295 in
Contact Length - Post [x]	3.56 mm
Contact Length - Post [x]	0.14 in
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Friction Lock
Insulation Color	Natural
Insulation Height	11.7 mm
Insulation Height	0.461 "
Insulation Material	Polyamide (PA), Nylon
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	14
Number of Positions Loaded	All
Number of Rows	1
Overall Contact Length	14.22 mm
Overall Contact Length	0.56 in
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Shrouding	Shrouded - 1 Wall
Style	Board to Cable/Wire
Termination	Solder

002227 Series

KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating

Part	Applications	Number of Rows	Number of Positions Loaded	Insulation Material	Contact Length - Mating	Contact Length - Mating	Pitch - Mating	Pitch - Mating	Contact Type	Overall Contact Length	Overall Contact Length	Insulation Height	Insulation Height	Style	Shrouding	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Mounting Type	Contact Length - Post [x]	Contact Length - Post [x]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Color	Termination	Material Flammability Rating	Connector Type	Number of Positions	Fastening Type	Contact Shape	Number of Positions
Molex 0022272081	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header	8	Friction Lock	Square
Molex 0022272161	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header		Friction Lock	Square	16
Molex 0022272031	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header		Friction Lock	Square
Molex 0022272141	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header	14	Friction Lock	Square
Molex 0022272051	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header		Friction Lock	Square
Molex 0022272041	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header	4	Friction Lock	Square
Molex 0022272121	Automotive General Purpose Medical Telecommunications	1	All	Nylon Polyamide (PA)	7.49 mm	0.295 in	0.1 in	2.54 mm	Male Pin	14.22 mm	0.56 in	11.7 mm	0.461 "	Board to Cable/Wire	Shrouded - 1 Wall	Tin	2.54 çm	100 çin	Brass	Through Hole	3.56 mm	0.14 in	2.54 µm	100 µin	Natural	Solder	UL94 V-0	Header	12	Friction Lock	Square

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 1.38
		10	$ 1.04
		100	$ 0.81
		500	$ 0.70
		1000	$ 0.66
		5000	$ 0.65

Description

General part information

002227 Series

KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
