UPT-04-01-01-L-RA - UPT-04-01-01-L-RA

UPT-04-01-01-L-RA

Active
Samtec Inc.

CONN HDR 4POS 3.81MM EDGE RA SLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet.150" PowerStrip™/20 A Dual Blade Power Terminal Strip+2
UPT-04-01-01-L-RA - UPT-04-01-01-L-RA

UPT-04-01-01-L-RA

Active
Samtec Inc.

CONN HDR 4POS 3.81MM EDGE RA SLD

Deep-Dive with AI

DocumentsDatasheet.150" PowerStrip™/20 A Dual Blade Power Terminal Strip+2

Technical Specifications

Parameters and characteristics for this part

SpecificationUPT-04-01-01-L-RA
ColorBlack
Connector TypeMale Blades, Header
Contact FinishGold
Contact Finish Thickness10 Áin
Contact Finish Thickness0.25 Ám
Contact MaterialBeryllium Copper
Current Rating (Amps)20 A
FeaturesBoard Guide
Material - InsulationLiquid Crystal Polymer (LCP)
Mounting TypeThrough Hole, Right Angle, Board Edge
Number of Positions4
Number of Rows1
Operating Temperature [Max]125 °C
Operating Temperature [Min]-55 °C
Pitch [x]0.15 in
Pitch [x]3.81 mm
TerminationSolder
Voltage Rating620 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyTube 1$ 4.88
25$ 4.42
50$ 4.10
100$ 4.09

Description

General part information

UPT-04 Series

4 Position Header, Male Blades Connector Solder 0.150" (3.81mm) Board Edge, Through Hole, Right Angle
