TRI 20-2411

Active

Traco Power

20 WATT DC/DC CONVERTER, INDUSTRIAL, 2-1 INPUT, REGULATED, REINFORCED HIGH ISOLATION (4200 VAC), HIGH WORKING VOLTAGE (1000 VAC), ENCAPSULATED, 2 X 1 INCH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TRI 20-2411

Active

Traco Power

20 WATT DC/DC CONVERTER, INDUSTRIAL, 2-1 INPUT, REGULATED, REINFORCED HIGH ISOLATION (4200 VAC), HIGH WORKING VOLTAGE (1000 VAC), ENCAPSULATED, 2 X 1 INCH

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TRI 20-2411

Applications	ITE (Commercial)
Approval Agency	CB, cURus
Current - Output (Max) [Max]	4 A
Efficiency	87 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	76 °C
Operating Temperature [Min]	-40 °C
Package / Case	4 Lead
Package / Case	5-DIP Module
Power (Watts)	20 W
Size / Dimension [x]	2 in
Size / Dimension [x]	50.8 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	12 mm
Size / Dimension [z]	0.47 "
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	8 kV
Voltage - Output 1	5.1 V

TRI 20 Series

Part	Voltage - Output 1	Approval Agency	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Number of Outputs	Package / Case	Package / Case	Type	Voltage - Isolation	Power (Watts)	Mounting Type	Efficiency	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 2
Traco Power TRI 20-4815	24 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	1	4 Lead	5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	75 V	36 V	-40 °C	76 °C
Traco Power TRI 20-4822	12 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	2		5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	75 V	36 V	-40 °C	76 °C	-12 V
Traco Power TRI 20-1222	12 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	2		5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	18 V	9 V	-40 °C	76 °C	-12 V
Traco Power TRI 20-2411	5.1 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	1	4 Lead	5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	87 %	4 A	36 V	18 V	-40 °C	76 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 76.20
		10	$ 74.32
		25	$ 71.96
		50	$ 68.42
		100	$ 63.70
		250	$ 58.40

Description

General part information

TRI 20 Series

Isolated Module DC DC Converter 1 Output 5.1V 4A 18V - 36V Input
