TRI 20-4815

Active

Traco Power

DC DC CONVERTER 24V 20W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER 24V 20W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Output 1	Approval Agency	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Number of Outputs	Package / Case	Package / Case	Type	Voltage - Isolation	Power (Watts)	Mounting Type	Efficiency	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 2
Traco Power TRI 20-4815	24 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	1	4 Lead	5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	75 V	36 V	-40 °C	76 °C
Traco Power TRI 20-4822	12 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	2		5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	75 V	36 V	-40 °C	76 °C	-12 V
Traco Power TRI 20-1222	12 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	2		5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	89 %	840 mA	18 V	9 V	-40 °C	76 °C	-12 V
Traco Power TRI 20-2411	5.1 V	CB cURus	ITE (Commercial)	12 mm	2 in	25.4 mm	25.4 mm	0.47 "	50.8 mm	1	4 Lead	5-DIP Module	Isolated Module	8 kV	20 W	Through Hole	87 %	4 A	36 V	18 V	-40 °C	76 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 24V 840mA 36V - 75V Input
