155-30802

Active

HELLERMANNTYTON

CBL CLIP BUNDLING BLACK FIR TREE

Search across all available documentation for this part.

Active

HELLERMANNTYTON

CBL CLIP BUNDLING BLACK FIR TREE

Technical Specifications

Parameters and characteristics for this part

Specification	155-30802

Color	Black
Features	UV Resistant, Heat Stabilized, Impact Resistant
Length [x]	55 mm
Length [x]	2.165 in
Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 HB
Material Thickness	0.059 in
Material Thickness	1.5 mm
Mounting Type	Fir Tree
Panel Hole Size [Max]	7 mm
Panel Hole Size [Max]	0.276 in
Panel Hole Size [Min]	6.3 mm
Panel Hole Size [Min]	0.248 in
Panel Thickness [Max]	0.201 "
Panel Thickness [Max]	5.1 mm
Panel Thickness [Min]	0.6 mm
Panel Thickness [Min]	0.024 in
Type	Bundling, Clip
Width	9 mm
Width	0.354 "

Part	Panel Hole Size [Min]	Panel Hole Size [Max]	Panel Hole Size [Min]	Panel Hole Size [Max]	Length	Length	Width [y]	Width [y]	Panel Thickness [Max]	Panel Thickness [Min]	Features	Color	Mounting Type	Bundle Center to Mounting Center	Bundle Center to Mounting Center	Type	Material	Height [z]	Height [z]	Material Flammability Rating	Type Attributes	Material Thickness	Material Thickness	Panel Thickness [Min]	Panel Thickness [Max]	Length [x]	Length [x]	Width	Width
HELLERMANNTYTON 155-30702	6.4 mm	7.1 mm	0.252 in	0.28 in	1.063 in	27 mm	0.394 in	10 mm	0.201 " 5.1 mm	0.028 in 0.7 mm	Heat Stabilized Impact Resistant UV Resistant	Black	Cupped Fir Tree	0.492 "	12.5 mm	Clip Connector	Polyamide (PA66) Nylon 6/6	5.59 mm	0.22 in	UL94 HB	Turnstop
HELLERMANNTYTON 155-30802	6.3 mm	7 mm	0.248 in	0.276 in					0.201 "	0.024 in	Heat Stabilized Impact Resistant UV Resistant	Black	Fir Tree			Bundling Clip	Polyamide (PA66) Nylon 6/6			UL94 HB		0.059 in	1.5 mm	0.6 mm	5.1 mm	55 mm	2.165 in	9 mm	0.354 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	14000	$ 0.11
