09160723111

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN DD SERIES, INSERT, 144+PE CONTACTS, 32B, RECEPTACLE

Search across all available documentation for this part.

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN DD SERIES, INSERT, 144+PE CONTACTS, 32B, RECEPTACLE

Technical Specifications

Parameters and characteristics for this part

Specification	09160723111

Color	Gray
Connector Type	Insert without Contacts
Contact Type	Han® D
Current Rating (Amps)	10 A
Gender	Female
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	16 B
Termination Style	Crimp
Voltage Rating	600 V

Part	Gender	Material Flammability Rating	Voltage Rating	Housing Material	Contact Type	Termination Style	Current Rating (Amps)	Color	Operating Temperature [Max]	Operating Temperature [Min]	Size	Connector Type
HARTING Technology Group 09160723011	Male	UL94 V-0	600 V	Polycarbonate (PC)	Han® D	Crimp	10 A	Gray	125 °C	-40 °C	16 B	Insert without Contacts
HARTING Technology Group 09160723101	Female	UL94 V-0	600 V	Polycarbonate (PC)	Han® D	Crimp	10 A	Gray	125 °C	-40 °C	16 B	Insert without Contacts
HARTING Technology Group 09160723001	Male	UL94 V-0	600 V	Polycarbonate (PC)	Han® D	Crimp	10 A	Gray	125 °C	-40 °C	16 B	Insert without Contacts
HARTING Technology Group 09160723111	Female	UL94 V-0	600 V	Polycarbonate (PC)	Han® D	Crimp	10 A	Gray	125 °C	-40 °C	16 B	Insert without Contacts

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Female Insert without Contacts Gray 72+Ground Position Crimp
