T0054461499N

Active

Apex Tool Group

DISPENSER NEEDLE TIP

Search across all available documentation for this part.

Active

Apex Tool Group

DISPENSER NEEDLE TIP

Technical Specifications

Parameters and characteristics for this part

Specification	T0054461499N

Diameter [diameter]	0.2 mm
Diameter [diameter]	0.008 in
For Use With/Related Products	WXMP, WMRP-MS, WXMP-MS, WMRP
Tip Shape	Conical
Tip Type	Soldering

Part	Diameter [diameter]	Diameter [diameter]	Tip Shape	For Use With/Related Products	Tip Type	Height [z]	Height [z]	Width	Width	Length	Length	Length [x]	Length [x]	Width [x]	Width [x]
Apex Tool Group T0054461999N	0.031 in	0.8 mm	Chisel 30°	WMRP WMRP-MS	Soldering	0.016 in	0.4 mm
Apex Tool Group T0054461899N	0.059 "	1.5 mm	Chisel	WMRP WMRP-MS	Soldering	0.016 in	0.4 mm
Apex Tool Group T0054461499N	0.008 in	0.2 mm	Conical	WMRP WMRP-MS WXMP WXMP-MS	Soldering
Apex Tool Group T0054461199N			Chisel	WMRP WMRP-MS WXMP WXMP-MS	Soldering	0.035 in	0.9 mm	3.6 mm	0.142 in	0.748 in	19 mm
Apex Tool Group T0054461699N			Chisel		Soldering							0.787 "	20 mm	0.051 in	1.3 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 32.00

General part information

DISPENSER NEEDLE TIP

Technical documentation and resources
