Technical Specifications
Parameters and characteristics for this part
| Specification | 1925812 |
|---|---|
| Color | Green |
| Contact Mating Finish | Tin |
| Current - IEC | 12 A |
| Current - UL | 10 A |
| Features | Retention Latches (Non-Wire Side), Latch Lock |
| Housing Material | Polyamide (PA), Nylon |
| Insulation Height | 0.591 in |
| Insulation Height | 15 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 14 |
| Pitch [x] | 0.2 in |
| Pitch [x] | 5.08 mm |
| Positions Per Level | 14 |
| Termination Style | Screwless - Push-In Spring |
| Type | Plug, Female Sockets |
| Voltage - IEC | 630 V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 26 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² |
| Wire Strip Length | 10 mm |
FKC Series
Pluggable Terminal Blocks 12 Pos 5.08mm pitch Plug 24-12AWG Spring
| Part | Number of Positions | Current - IEC | Type | Contact Mating Finish | Insulation Height | Insulation Height | Voltage - UL | Housing Material | Number of Levels | Positions Per Level | Mounting Type | Termination Style | Voltage - IEC | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Current - UL | Wire Strip Length | Pitch [x] | Pitch [x] | Color | Material Flammability Rating | Wire Gauge or Range - mm˛ [Min] | Wire Gauge or Range - mm˛ [Max] | Features | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact | 6 | 12 A | Plug Female Sockets | Tin | 0.591 in | 15 mm | 300 V | Polyamide (PA) Nylon | 1 | 6 | Free Hanging (In-Line) | Push-In Spring Screwless - Leg Spring | 630 V | 12 AWG | 26 AWG | 10 A | 10 mm | 5 mm | 0.197 in | Green | UL94 V-0 | 0.2 mm˛ | 2.5 mm˛ | |||
Phoenix Contact | 15 | 12 A | Plug Female Sockets | Tin | 0.591 in | 15 mm | 300 V | Polyamide (PA) Nylon | 1 | 15 | Free Hanging (In-Line) | Screwless - Push-In Spring | 630 V | 12 AWG | 26 AWG | 10 A | 10 mm | 5.08 mm | 0.2 in | Green | UL94 V-0 | Latch Lock Retention Latches (Non-Wire Side) | 0.2 mm² | 2.5 mm² | ||
Phoenix Contact | 14 | 12 A | Plug Female Sockets | Tin | 0.591 in | 15 mm | 300 V | Polyamide (PA) Nylon | 1 | 14 | Free Hanging (In-Line) | Screwless - Push-In Spring | 630 V | 12 AWG | 26 AWG | 10 A | 10 mm | 5.08 mm | 0.2 in | Green | UL94 V-0 | Latch Lock Retention Latches (Non-Wire Side) | 0.2 mm² | 2.5 mm² | ||
Phoenix Contact | 12 | 12 A | Plug Female Sockets | Tin | 0.591 in | 15 mm | 300 V | Polyamide (PA) Nylon | 1 | 12 | Free Hanging (In-Line) | Screwless - Push-In Spring | 630 V | 12 AWG | 26 AWG | 10 A | 10 mm | 5.08 mm | 0.2 in | Green | UL94 V-0 | Ejector Latches Retention Latches (Non-Wire Side) | 0.2 mm² | 2.5 mm² | ||
Phoenix Contact | 16 A | Plug Female Sockets | Tin | 0.591 in | 15 mm | 300 V | Polyamide (PA) Nylon | 1 | 5 | Free Hanging (In-Line) | Screwless - Push-In Spring | 630 V | 12 AWG | 26 AWG | 16 A | 10 mm | 5.08 mm | 0.2 in | Green | UL94 V-0 | 0.2 mm² | 2.5 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
FKC Series
Pluggable Terminal Blocks 12 Pos 5.08mm pitch Plug 24-12AWG Spring
